INITIAL SETTING VALUE OF SERVICE MENU
1. Adjustment of the SERVICE MENU is made on the basis of the initial setting values ; however, the new setting values which set
the screen in its optimum condition may differ from the initial setting.
2. Do not change the initial Setting Values of the Setting (Adjustment) items not listed In “ADJUSTMENT”.
z
INITIAL SETTING VAKUE of V/C
Initial setting value
Colour system
Setting item
Variable
range
PAL SECAM NTSC 3.58 NTSC 4.43
RED
GREEN
1. CUT OFF
BLUE
-128
～
+127
-50
RED
2. DRIVE
BLUE
-128
～
+127
+ 0
3. BRIGHT
-127
～
+127
+ 0
4. CONT.
-63
～
+63
+ 0
5. COLOUR
-63
～
+63
+ 0
TV
+ 0 + 0
6. TINT
VIDEO
-63
～
+63
+ 0 + 0
7. SECAM BL ADJ.
-31
～
+31
+ 0
TV
- 15
8. SHARP
(Do Not Adj.)
VIDEO
-32
～
+31
+15
z
INITIAL SETTING VALUE of DEFLECTION
Initial setting value
Setting item Variable range
fv : 50Hz MODE fv : 60Hz MODE
1. VER. POSITION
-04
～
～～
～
+03 + 0 - 3
2. HOR. POSITION
-16
～
～～
～
+15
- 2 + 7
3. VER. HEIGHT
-64
～
～～
～
+63
-24 - 2
4. VER. LINEARITY
-32
～
～～
～
+31
+13 - 5
5. VER. SCURVE
-32
～
～～
～
+31
-32 + 0
6. HOR. VCO ADJUST
-63
～
～～
～
+62 + 0 + 0
z
SETTING VALUE OF VSM PRESET
VSM preset
VSM mode
Setting item
BRIGHT
STANDARD
SOFT
TINT
SETTING VALUE
+15
COLOUR
SETTING VALUE
+15
BRIGHT
SETTING VALUE
+15
CONT.
SETTING VALUE
+30 +15 +11
SHARP
SETTING VALUE
+15 +12
