Specifications
Amplifier
CA-D501T/MX-D401T
Output Power (IEC 268-3/DIN) 27 watts per channel, min. RMS, both channels driven into 6 ohms at 1 kHz with no more
than 0.9% total harmonic distortion.
MX-D301T
Output Power (IEC 268-3/DIN) 12 watts per channel, min. RMS, both channels driven into 4 ohms at 1 kHz with no more
than 0.9% total harmonic distortion.
Input Sensitivity/Impedance (1 kHz)
AUX 300 mV/50 kohms
MIC 1 3 mV/2 kohms
MIC 2 3 mV/2 kohms
CA-D501T/MX-D401T
Speaker terminals 6 - 16 ohms
MX-D301T
Speaker terminals Minimum 4 ohms
Cassette Deck
Frequency Response
Type II (CrO
2
) : 50 - 14,000 Hz
Type I (NORMAL) : 50 - 14,000 Hz
Wow And Flutter 0.15% (WRMS)
CD Automatic Changer
CD Capacity 3 discs
Dynamic Range 85 dB
Signal-To-Noise Ratio 90 dB
Wow And Flutter Unmeasurable
Tuner
FM Tuner
Tuning Range 87.5 - 108.0 MHz
AM Tuner
Tuning Range 531 - 1,602 kHz (at 9 kHz channel space)
530 - 1,710 kHz (at 10 kHz channel space)
CA-D501T/MX-D401T
Dimensions (W/H/D) 265 × 295 × 339 mm
(10-7/16 × 11-5/8 × 13-3/8 inches)
Mass 7.1 kg (15.7 lbs)
MX-D301T
Dimensions (W/H/D) 265 × 295 × 339 mm
(10-7/16 × 11-5/8 × 13-3/8 inches)
Mass 6.7 kg (14.8 lbs)
Speaker Specifications
SP-D401
Type 3- way, 3-speaker bass-reflex type
Speakers
Woofer 16 cm (6-5/16 inches) cone × 1
Mid Range 5 cm (2 inches) cone × 1
Tweeter 2 cm (13/16 inches) dome × 1
Power Hardling Capacity 80 watts
Impedance 6 ohms
Frequecy Range 45 Hz - 20,000 Hz
Sound Pressure Level 90 dB/w • m
Dimensions (W/H/D) 215 × 295 × 275 mm
(8-1/2 × 11-5/8 × 10-7/8 inches)
Mass 3.2 kg (7.1 lbs) each
