3-27
Amplifier board (DX-T99)
Block No. [0][2]
R8172 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8173 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8174 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R8175 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8180 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R8182 QRE141J-163Y C RESISTOR 16k
Ω
1/4W J
R8183 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R8186 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R8187 QRE141J-272Y C RESISTOR 2.7k
Ω
1/4W J
R8189 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R8190 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R8191 QRE141J-154Y C RESISTOR 150k
Ω
1/4W J
R8192 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R8193 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R8194 NRSA63J-133X MG RESISTOR 13k
Ω
1/16W J
R8195 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R8196 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8198 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R8199 QRE141J-105Y C RESISTOR 1M
Ω
1/4W J
R8202 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8203 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R8204 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R8205 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8206 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8211 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R8212 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8223 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8224 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8225 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8230 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R8231 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R8232 QRE141J-753Y C RESISTOR 75k
Ω
1/4W J
R8235 QRE141J-224Y C RESISTOR 220k
Ω
1/4W J
R8260 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R8261 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R8262 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R8263 NRSA63J-475X MG RESISTOR 4.7M
Ω
1/16W J
R8264 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R8265 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R8266 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R8267 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R8268 NRSA63J-622X MG RESISTOR 6.2k
Ω
1/16W J
R8269 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R8293 QRE141J-393Y C RESISTOR 39k
Ω
1/4W J
R8335 QRE141J-224Y C RESISTOR 220k
Ω
1/4W J
R8401 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R8402 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R8403 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R8404 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R8405 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R8407 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8409 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R8430 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R8431 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R8432 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R8433 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R8434 NRSA63J-824X MG RESISTOR 820k
Ω
1/16W J
R8435 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8507 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R8508 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8509 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8510 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8511 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8512 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8513 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8514 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R8521 QRE141J-243Y C RESISTOR 24k
Ω
1/4W J
R8523 QRZ9006-4R7X FUSI RESISTOR 4.7
Ω
R8524 QRE141J-561Y C RESISTOR 560
Ω
1/4W J
R8529 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
R8539 QRE141J-822Y C RESISTOR 8.2k
Ω
1/4W J
R8551 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R8574 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R8575 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R8578 QRE141J-681Y C RESISTOR 680
Ω
1/4W J
R8579 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R8810 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R8811 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
Symbol No.
Part No. Part Name Description Local
R8900 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R9000 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9001 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9002 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9003 NRSA63J-274X MG RESISTOR 270k
Ω
1/16W J
R9004 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R9005 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9006 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R9007 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R9010 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9011 NRSA63J-824X MG RESISTOR 820k
Ω
1/16W J
R9012 NRSA63J-163X MG RESISTOR 16k
Ω
1/16W J
R9013 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9014 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9015 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R9017 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9021 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9022 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9030 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R9031 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R9032 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R9033 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R9034 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9035 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R9036 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R9101 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9102 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9103 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9104 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
VR901 QVQ0342-B24 V RESISTOR
L9100 QQL231K-2R2Y COIL 2.2uH K
L9101 QQL231K-470Y COIL 47uH K
L9102 QQL231K-470Y COIL 47uH K
CN720 QGF1036C2-19 CONNECTOR FFC/FPC (1-19)
CN730 QGF1205C2-25 CONNECTOR FFC/FPC (1-25)
CN740 QGF1205F2-05 CONNECTOR FFC/FPC (1-5)
CN750 QGF1205F2-11 CONNECTOR FFC/FPC (1-11)
CN760 QGF1205C2-08 CONNECTOR FFC/FPC (1-8)
CN787 QGF1210G1-05 CONNECTOR FFC/FPC (1-5)
CN800 QGF1036C2-10 CONNECTOR FFC/FPC (1-10)
CN810 QGF1036C2-08 CONNECTOR FFC/FPC (1-8)
CN820 QGF1205C2-08 CONNECTOR FFC/FPC (1-8)
CN830 QGF1205C2-19 CONNECTOR FFC/FPC (1-19)
CN850 QGB2510J1-15 CONNECTOR B-B (1-15)
CN860 QGB2510K2-06 CONNECTOR B-B (1-6)
CN901 QGF1205F2-05 CONNECTOR FFC/FPC (1-5)
FW910 QUM153-21DGZ4-E FLAT WIRE
J700 QNB0300-003 SPK TERMINAL
J800 QNN0420-001 SURROUND JACK
J901 QNS0252-001 MIC JACK
J902 QNS0252-001 MIC JACK
J910 QNS0266-001 JACK
K8000 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K8001 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K9100 QQR0621-001Z COIL
RY712 QSK0109-001 RELAY
RY734 QSK0109-001 RELAY
RY750 QSK0109-001 RELAY
RY767 QSK0109-001 RELAY
X7700 QAX0711-002Z CRYSTAL 8.000000MHz
Symbol No.
Part No. Part Name Description Local
IC301 STK413-430 IC
IC302 KIA7809API IC
IC303 KIA7805API IC
IC304 KIA7810API IC
IC305 KIA278R05PI IC
IC306 KIA278R09PI IC
Symbol No.
Part No. Part Name Description Local
