JVC CA-MXDK3

SCHEMATIC DIAGRAMS
MX-DK1US,MX-DK1UW,MX-DK1UG
MX-DK1UN,MX-DK3US,MX-DK3UW
MX-DK3UG,MX-DK3UN,MX-DK15UN
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-11 to 14
CD-ROM No.SML200606
COMPACT COMPONENT SYSTEM
No.MB515SCH
2006/6
COPYRIGHT 2006 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
CA-MXDK1SP-MXDK1F SP-MXDK1F
CA-MXDK15SP-MXDK15F SP-MXDK15F
CA-MXDK3 SP-MXDK3FSP-MXDK3F SP-MXDK3W
