5
LOW
HIGH
RGB
Y/C
Y
P
B
P
R
FM antenna (supplied)
Extend it so that you can
obtain the best reception.
AM loop antenna (supplied)
Turn it until the best reception is
obtained.
AM loop antenna
Keep it connected.
Vynile-covered wire (not supplied)
Extend it horizontally.
Disconnect the supplied FM antenna, and connect to an outdoor FM antenna
using a 75 Ω wire with coaxial type connector (IEC or DIN45325).
Outdoor FM
antenna
(not supplied)
For better FM/AM reception
To a wall outlet
Plug the AC power cord only after all connections and
selector settings on the rear are complete.
Connection.fm Page 5 Tuesday, February 17, 2004 10:25 PM
To Next Page
