SPECIFICATIONS
Camcorder
Power supply
DC 11.0 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
Approx. 3.3 W (LCD monitor off, viewfinder on)
Approx. 4.6 W (LCD monitor on, viewfinder off)
Approx. 8.6 W (Maximum)
Dimensions (W x H x D)
71 mm x 91 mm x 118 mm
(with the LCD monitor closed and the viewfinder pushed
back in)
Weight
Approx. 500 g
(without cassette and battery)
Approx. 590 g
(incl. cassette and battery)
Operating temperature
0°C to 40°C
Operating humidity
35% to 80%
Storage temperature
–20°C to 50°C
Pickup
1/6" CCD
Lens
F 1.6, f = 2.7 mm to 43.2 mm, 16:1 power zoom lens
Filter diameter
ø30.5 mm
LCD monitor
2.37" diagonally measured, LCD panel/TFT active matrix
system
Viewfinder
Electronic viewfinder with 0.24" colour LCD
Speaker
Monaural
White LED Light
Effective distance: 1.5 m
Format
DV format (SD mode)
Signal format
PAL standard
Recording/Playback format
Video: Digital component recording
Audio: PCM digital recording, 32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
Cassette
Mini DV cassette
Tape speed
SP: 18.8 mm/s, LP: 12.5 mm/s
Maximum recording time (using 80 min. cassette)
SP: 80 min., LP: 120 min
S
S-Video output:
Y: 1.0 V (p-p), 75 Ω, analogue
C: 0.29 V (p-p), 75 Ω, analogue
AV
Video output: 1.0 V (p-p), 75 Ω, analogue
Audio output: 300 mV (rms), 1 kΩ, analogue, stereo
DV
Output: 4-pin, IEEE 1394 compliant
AC Adapter
Power requirement
AC 110 V to 240 Vd, 50 Hz/60 Hz
Output
DC 11 V G, 1 A
Specifications shown are for SP mode unless otherwise
indicated. E & O.E. Design and specifications subject to
change without notice.
For General
For Digital Video Camera
For Connectors
