[5] Function
Use this function to set command communications, remote control codes,
OFF timer function, etc. You can also reset the lamp time.
Use the UP/DOWN keys to select an adjustment item.
Press the [BACK] key to return to the previous screen.
Items Explanation, operation, precautions, settings
Trigger
Congures 12V output to an external screen equipped with a trigger function.
Settings: Off, On(Power), On(Anamo) [Off]
Off
No output.
On (Power) When turned on, control signals (12V) from the trigger terminal are emitted.
If you turn off the power, the output of the control signal stops.
During standby mode, an output will occur if the [OK] button is pressed.
After cooling, the output stops when you go back to standby.
On (Anamo) Control signals (12V) are emitted when the Anamorphic mode is set from "Off” to “A” or
“B”. If the Anamorphic mode is set to "A" or "B", the operation in this state equals "On
(Power)".
Off Timer
Sets Off Timer function and its time.
(*) If there are no operations, the unit powers off automatically.
(*) It powers off automatically even while projecting an image.
(*) You will be given a warning 60 seconds before power turns OFF.
Press the [OK] button while the warning is being displayed to delete the warning display.
You cannot congure settings to omit warning display.
Settings: Off, 1 hour, 2 hours, 3 hours, 4 hours [Off]
Off
Power is not turned off.
1 Hour
Power is turned off automatically after 1 hour.
2 Hours
Power is turned off automatically after 2 hours.
3 Hours
Power is turned off automatically after 3 hours.
4 Hours
Power is turned off automatically after 4 hours.
High Altitude Mode
Set to use at low pressure locations (900m above sea level).
Settings: On, Off [Off]
On
Set.
Off
Do not set.
Communication
Terminal
Sets the used control terminal. It is not possible to use it at the same time.
Settings: RS-232C, LAN [RS-232C]
RS-232C Sets the RS-232C terminal.
LAN Sets the LAN terminal.
Network It is displayed, if the setting of the "Communication terminal” to the submenu "[5-1]
Network" is set to "LAN".
Remote Code
Use this function to change the projector's remote control code. The projector can be
operated only with a remote control congured with the same code. To change the remote
control code itself, press "MENU" and [BACK] together for three seconds or more. All of
the buttons on the remote control will begin to blink. Two blinks indicate "Change A to B";
three blinks indicate "Change B to A".
Settings: A, B [A]
A Set the projector's remote control code to "A".
B Set the projector's remote control code to "B".
Lamp Reset Reset of the lamp use time to "0".
Adjustments and settings in the menu (continued)
Trigger
Off Timer
Remote Code
Network
Lamp Reset
Remote Code
High Altitude Mode
Off
Off
Off
RS-232C
A
