JVC DR-MX10SE - Page 45

(No.YD084)3-17
DC/DC Converter board
Block No. [1][1]
A/C Head board
Block No. [1][2]
Demodulator board
Block No. [1][4]
Operation/jack board
Block No. [2][7]
 Symbol No. Part No. Part Name Description Local
PW1 LPA20041-02B DC/DC CONVERTER BOARD ASSY
IC5701 BD9851EFV-X IC
IC5710 QS5U27-W MOS FET
Q5720 RTQ035P02-W MOS FET
D5710 RB520S-30-X SB DIODE
D5720 RB520S-30-X SB DIODE
D5721 SX34-X SB DIODE
D5721 or RB051L-40-X SB DIODE
C5710 NCB31HK-681X C CAPACITOR 680pF 50V K
C5711 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5712 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5713 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5714 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C5716 NDC31HJ-151X C CAPACITOR 150pF 50V J
C5720 NCB31HK-681X C CAPACITOR 680pF 50V K
C5721 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5722 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5723 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5724 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C5726 NCB31HK-331X C CAPACITOR 330pF 50V K
C5727 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5730 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5731 NDC31HJ-101X C CAPACITOR 100pF 50V J
C5732 NCB31CK-223X C CAPACITOR 0.022uF 16V K
R5710 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R5711 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R5712 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5713 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5720 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R5721 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R5722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5723 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5730 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5731 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R5732 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
L5710 NQL82EN-100X COIL 10uH N
L5720 NQR0562-001X CHOKE COIL
CN5701 QGG2009M1-13 CONNECTOR (1-13)
CN5702 QGG2009M1-03 CONNECTOR (1-3)
K5710 NQR0499-002X FERRITE BEADS
K5720 NQR0499-002X FERRITE BEADS
 Symbol No. Part No. Part Name Description Local
PW1 LPA10158-01A1 A/C HEAD BOARD ASSY
 Symbol No. Part No. Part Name Description Local
PW1 LPA10292-04A DEMODULATOR BOARD ASSY EF
PW1 LPA10292-03A DEMODULATOR BOARD ASSY E,EK
IC6701 MSP3417GQGB8V3X IC
D6701 1SS133-T2 SI DIODE
D6701 or 1SS270A-T2 SI DIODE
C6704 NCB31HK-103X C CAPACITOR 0.01uF 50V K EF
C6704 NCB30JK-105X C CAPACITOR 1uF 6.3V K E,EK
C6707 NDC31HJ-470X C CAPACITOR 47pF 50V J
C6708 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C6709 NDC31HJ-150X C CAPACITOR 15pF 50V J EF
C6709 NDC31HJ-8R0X C CAPACITOR 8pF 50V J E,EK
C6713 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C6714 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6715 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C6716 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6717 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C6719 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C6720 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C6721 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6723 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6724 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M EF
R6707 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R6708 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6709 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6710 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6711 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6712 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6713 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R6714 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6715 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R6716 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R6719 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6720 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6721 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
B6701 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
CN6701 QGG2502K1-10 CONNECTOR (1-10)
K6701 NQR0129-003X FERRITE BEADS
K6702 NQR0129-003X FERRITE BEADS
K6705 NQR0129-003X FERRITE BEADS
K6706 NQR0129-003X FERRITE BEADS
K6707 NQR0129-003X FERRITE BEADS EF
K6708 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W6701 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
X6701 QAX0773-001Z CRYSTAL 18.432000MHz
OT1 LP40425-001A BRACKET(PWB)
 Symbol No. Part No. Part Name Description Local
PW1 LPA10298-03B5 OPERATON JACK BOARD ASSY
C7202 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C7204 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C7206 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R7202 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R7206 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R7207 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
L7202 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
L7203 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
CN7201 QGF1208C1-09 CONNECTOR FFC/FPC (1-9)
CN7202 QGD2503C1-04 CONNECTOR (1-4)
J7201 QNN0591-001 PIN JACK FRONT AV
J7204 QND0084-001 S JACK FRONT S
S7216 QSW0381-001Z TACT SWITCH VHS_EJECT
S7218 QSW0381-001Z TACT SWITCH OPE
