3-18(No.YD084)
Switch/Display board
Block No. [2][8]
DV Jack board
Block No. [3][6]
Digital board
Block No. [5][0]
Symbol No.
Part No. Part Name Description Local
PW1 LPA10298-03B4 DISPLAY/SWITCH BOARD ASSY
IC7001 PT6315 IC
IC7002 GP1UM281XKVF IR DETECT UNIT
IC7002 or PNA4652M00XB IR DETECT UNIT 38kHz
Q7001 UN221L-X DIGI TRANSISTOR
Q7001 or DTC143EKA-X DIGI TRANSISTOR
Q7001 or RT1N431C-X DIGI TRANSISTOR
Q7002 UN221L-X DIGI TRANSISTOR
Q7002 or DTC143EKA-X DIGI TRANSISTOR
Q7002 or RT1N431C-X DIGI TRANSISTOR
Q7003 UN221L-X DIGI TRANSISTOR
Q7003 or DTC143EKA-X DIGI TRANSISTOR
Q7003 or RT1N431C-X DIGI TRANSISTOR
D7001 1SS133-T2 SI DIODE
D7001 or 1SS270A-T2 SI DIODE
D7002 1SS133-T2 SI DIODE
D7002 or 1SS270A-T2 SI DIODE
D7003 1SS133-T2 SI DIODE
D7003 or 1SS270A-T2 SI DIODE
D7004 1SS133-T2 SI DIODE
D7004 or 1SS270A-T2 SI DIODE
D7005 1SS133-T2 SI DIODE
D7005 or 1SS270A-T2 SI DIODE
D7012 1SS133-T2 SI DIODE
D7012 or 1SS270A-T2 SI DIODE
D7013 1SS133-T2 SI DIODE
D7013 or 1SS270A-T2 SI DIODE
D7014 1SS133-T2 SI DIODE
D7014 or 1SS270A-T2 SI DIODE
D7015 1SS133-T2 SI DIODE
D7015 or 1SS270A-T2 SI DIODE
D7016 1SS133-T2 SI DIODE
D7016 or 1SS270A-T2 SI DIODE
D7021 MTZJ9.1B-T2 Z DIODE
D7041 SLR343WBCT3 LED VHS
D7042 SLR-343VC-T LED VHS REC
D7043 SLR-343VC-T LED HDD REC
D7044 SLR-343VC-T LED DVD REC
D7045 SDPB50A0/DEGH/ LED BLUE LIGHT
D7045 or SLA-580BC3T3F LED BLUE LIGHT
D7046 SLR343WBCT3 LED HDD
D7047 SLR343WBCT3 LED DVD
D7048 SDPB50A0/DEGH/ LED BLUE LIGHT
D7048 or SLA-580BC3T3F LED BLUE LIGHT
C7001 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C7002 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7003 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C7006 QEKC0JM-227Z E CAPACITOR 220uF 6.3V M
C7007 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7008 QERF1AM-227Z E CAPACITOR 220uF 10V M
C7010 NCF31HZ-473X C CAPACITOR 0.047uF 50V Z
C7011 NCF31HZ-473X C CAPACITOR 0.047uF 50V Z
R7001 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7002 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7003 QRE141J-823Y C RESISTOR 82k
Ω
1/4W J
R7005 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R7006 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7007 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7009 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7010 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7013 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R7014 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R7015 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7022 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R7035 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7041 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R7042 QRE141J-181Y C RESISTOR 180
Ω
1/4W J
R7043 QRE141J-181Y C RESISTOR 180
Ω
1/4W J
R7044 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7045 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7046 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R7047 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R7048 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
CN7001 QGF1209F2-15 CONNECTOR FFC/FPC (1-15)
DI7001 QLF0143-001 FL TUBE
FW7001
QUM024-07A4BF-E
PARA RIBON WIRE
HD1 PQ34949-1-1 FL HOLDER(L) FOR DI7001
HD2 PQ34950-1-1 FDP HOLDER(R) FOR DI7001
S7002 QSW0381-001Z TACT SWITCH CH+
S7004 QSW0381-001Z TACT SWITCH DOWN
S7012 QSW0381-001Z TACT SWITCH VHS/HD/DVD
S7013 QSW0381-001Z TACT SWITCH RIGHT
S7014 QSW0381-001Z TACT SWITCH PAUSE
S7015 QSW0381-001Z TACT SWITCH STOP
S7022 QSW0381-001Z TACT SWITCH CH-
S7023 QSW0381-001Z TACT SWITCH UP
S7024 QSW0381-001Z TACT SWITCH GUIDE
S7032 QSW0381-001Z TACT SWITCH OPEN/CLOSE
S7033 QSW0381-001Z TACT SWITCH LEFT
S7034 QSW0381-001Z TACT SWITCH REC
S7035 QSW0381-001Z TACT SWITCH PLAY
S7036 QSW0381-001Z TACT SWITCH NAVI
S7037 QSW0381-001Z TACT SWITCH DUB
S7038 QSW0381-001Z TACT SWITCH SET
W41 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W42 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W43 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W44 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W45 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
PW1 LPA10298-03A3 DV JACK BOARD ASSY
CN4104 QGB1231M1-09 CONNECTOR B-B (1-9)
GN4101 QNZ0136-001Z EARTH PLATE
J4112 QNZ0675-001 D CONNECTOR F-DV
Symbol No.
Part No. Part Name Description Local
PW1 LPA10300-05C DIGITAL BOARD ASSY
IC1001 JCP8059-2 IC
IC1002
HY57V161610ETP7
IC
IC1002 or
K4S161622H-UC60
IC
IC1201 LPN0986-001A IC(FLASH) (SERVICE)
IC1202
SN74LVC373APW-X
IC(DIGITAL)
IC1203
SN74LVC373APW-X
IC(DIGITAL)
IC1401 DMN8652-B0L IC(DIGITAL)
IC1404
SN74HCT08APW-X
IC
IC1601
HY5DU561622DT-J
IC
IC1602
HY5DU561622DT-J
IC
IC1603
HY5DU561622DT-J
IC
IC1604
HY5DU561622DT-J
IC
IC1701 BD3533F-X IC
IC1801 TSB41AB1PAP IC
IC1901
TVP5150AM1PBS-W
IC
Symbol No.
Part No. Part Name Description Local
