SCHEMATIC DIAGRAMS
DX-J36UN,DX-J36EE,DX-J36UX,DX-J36UG
DX-J36US,DX-J36UW,DX-J21UN,DX-J21J
DX-J21EE,DX-J21A,DX-J21UW,DX-J21UX
DX-J21UG,DX-J11UN,DX-J11EE,DX-J11UW
DX-J11UX,DX-J11UG,DX-J11UH,DX-J11US
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-20 to 22
DVD-ROM No.SML2008Q4
COMPACT COMPONENT SYSTEM
No.MB666SCH<Rev.005>
2009/2
COPYRIGHT 2009 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
SUPER VIDEO
DX-J11
SP-DXJ11 CA-DXJ11 SP-DXJ11
DX-J21
SP-DXJ21W SP-DXJ21F CA-DXJ21 SP-DXJ21F
DX-J36
SP-DXJ36F SP-DXJ36F
SP-DXJ36C
CA-DXJ36
SP-DXJ36S SP-DXJ36S
