JVC DX-J36UN Service Manual

3-15
AMP board (For J21 & J11 ver)
Block No. [0][2]
S1104 QSW0683-001Z PUSH SW
S1105 QSW0683-001Z PUSH SW
S1106 QSW0683-001Z PUSH SW
S1107 QSW0683-001Z PUSH SW
S1108 QSW0683-001Z PUSH SW
S1109 QSW0683-001Z PUSH SW
S1110 QSW0683-001Z PUSH SW
S1111 QSW0683-001Z PUSH SW
S1201 QSW0683-001Z PUSH SW
S1202 QSW0683-001Z PUSH SW
S1203 QSW0683-001Z PUSH SW
S1204 QSW0683-001Z PUSH SW
S1205 QSW0683-001Z PUSH SW
S1206 QSW0683-001Z PUSH SW
S1207 QSW0683-001Z PUSH SW
S1208 QSW0683-001Z PUSH SW
S1209 QSW0683-001Z PUSH SW
S1210 QSW0683-001Z PUSH SW
S1301 QSW0683-001Z PUSH SW
S1302 QSW0683-001Z PUSH SW
S1303 QSW0683-001Z PUSH SW
S1304 QSW0683-001Z PUSH SW
S1305 QSW0683-001Z PUSH SW
S1306 QSW0683-001Z PUSH SW
S1307 QSW0683-001Z PUSH SW
S1308 QSW0683-001Z PUSH SW
S1309 QSW0683-001Z PUSH SW
S1310 QSW0683-001Z PUSH SW
WC800 QZW0112-001 WIRE CLAMP 36EE,
36UX,
36UG,
36US,
36UW
! Symbol No. Part No. Part Name Description Local
IC101 PT6324-HT FL DRIVER
IC102 GP1UM281XKVF IR DETECT UNIT
IC730 R2S15207FP-X IC
IC750 NJM4565E-X IC
IC751 TC4066BFT-X IC(DIGITAL)
IC770 RT3Y97M-X TR ARRAY
IC780 NJM4565E-X IC 21UN,21J,21EE
,21A,21UW,21U
X,21UG
! IC820 STK416-100-E POWER IC 21UN,21J,21EE
,21A,21UW,21U
X,21UG
! IC820 STK415-100-E POWER IC 11UN,11EE,11U
W,11UX,11UG,1
1UH,11US
Q1001 RT1N140C-X DIGI TRANSISTOR
Q1002 RT1N140C-X DIGI TRANSISTOR
Q1003 RT1N140C-X DIGI TRANSISTOR
Q7400 RT6N140C-X CHIP TR
Q7405 RT6N140C-X CHIP TR
Q7410 RT6N140C-X CHIP TR
Q7415 RT6N140C-X CHIP TR
Q7420 2SC5938A/B/-X TRANSISTOR
Q7430 2SC5938A/B/-X TRANSISTOR
Q7515 RT1N441C-X TRANSISTOR
Q7516 RT1N441C-X TRANSISTOR
Q7600 RT6N140C-X CHIP TR
Q7605 RT6N140C-X CHIP TR
Q7610 RT6N140C-X CHIP TR
Q7615 RT6N140C-X CHIP TR
Q7620 RT6N140C-X CHIP TR
Q7630 RT6N140C-X CHIP TR
Q7750 RT6N140C-X CHIP TR 21UN,21J,21EE
,21A,21UW,21U
X,21UG
Q8100 KTC3200/GL/-T TRANSISTOR
! Symbol No. Part No. Part Name Description Local
Q8101 ISA1530AC1/QR/X TRANSISTOR
Q8102 2SC3928A/QR/-X TRANSISTOR
Q8103 KTA1268/GL/-T TRANSISTOR
Q8210 KTC3199/GL/-T TRANSISTOR
Q8220 KTC3199/GL/-T TRANSISTOR
Q8250 KTC3199/GL/-T TRANSISTOR 21UN,21J,21EE
,21A,21UW,21U
X,21UG
Q8400 2SC3928A/QR/-X TRANSISTOR
D1001 SLR-343VC-T LED
D1002 SLR-343VC-T LED
D1003 SLR-343VC-T LED
D7440 MA111-X SI DIODE
D7441 MA111-X SI DIODE
D7442 MA111-X SI DIODE
D7640 MA111-X SI DIODE
D7641 MA111-X SI DIODE
D7642 MA111-X SI DIODE
D8100 MA111-X SI DIODE
D8200 UDZW15B-X Z DIODE
D8201 UDZW36B-X Z DIODE
D8202 UDZW15B-X Z DIODE
D8203 UDZW36B-X Z DIODE
D8204 1N5402M-20 SI DIODE
D8205 1N5402M-20 SI DIODE
D8210 MA111-X SI DIODE
D8220 MA111-X SI DIODE
D8250 MA111-X SI DIODE 21UN,21J,21EE
,21A,21UW,21U
X,21UG
D8310 MA111-X SI DIODE
D8320 MA111-X SI DIODE
D8400 MA111-X SI DIODE
C1008 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1010 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1012 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1013 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1015 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1029 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7040 QETN1AM-108Z E CAPACITOR 1000uF 10V M
C7050 QEZ0863-107Z E CAPACITOR 100uF
C7140 QETN1AM-477Z E CAPACITOR 470uF 10V M
C7300 QEZ0863-336Z E CAPACITOR 33uF
C7301 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7302 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7303 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7304 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7306 QEZ0863-106Z M CAPACITOR 10uF
C7307 QFG32AJ-472Z PP CAPACITOR 4700pF 100V J 21UN,21J,21EE
,21A,21UW,21U
X,21UG
C7307 QFG32AJ-272Z PP CAPACITOR 2700pF 100V J 11UN,11EE,11U
W,11UX,11UG,1
1UH,11US
C7308 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C7309 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J 21UN,21J,21EE
,21A,21UW,21U
X,21UG
C7309 QFLC1HJ-822Z M CAPACITOR 8200pF 50V J 11UN,11EE,11U
W,11UX,11UG,1
1UH,11US
C7310 QEZ0863-336Z E CAPACITOR 33uF
C7311 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7312 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7313 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7314 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7316 QEZ0863-106Z M CAPACITOR 10uF
C7317 QFG32AJ-472Z PP CAPACITOR 4700pF 100V J 21UN,21J,21EE
,21A,21UW,21U
X,21UG
C7317 QFG32AJ-272Z PP CAPACITOR 2700pF 100V J 11UN,11EE,11U
W,11UX,11UG,1
1UH,11US
C7318 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C7319 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J 21UN,21J,21EE
,21A,21UW,21U
X,21UG
! Symbol No. Part No. Part Name Description Local
