JVC DX-J36UN Service Manual

3-19
MICOM board (Only J36 ver)
Block No. [0][3]
S1205 QSW0683-001Z PUSH SW
S1206 QSW0683-001Z PUSH SW
S1207 QSW0683-001Z PUSH SW
S1208 QSW0683-001Z PUSH SW
S1209 QSW0683-001Z PUSH SW
S1210 QSW0683-001Z PUSH SW
S1301 QSW0683-001Z PUSH SW
S1302 QSW0683-001Z PUSH SW
S1303 QSW0683-001Z PUSH SW
S1304 QSW0683-001Z PUSH SW
S1305 QSW0683-001Z PUSH SW
S1306 QSW0683-001Z PUSH SW
S1307 QSW0683-001Z PUSH SW
S1308 QSW0683-001Z PUSH SW
S1309 QSW0683-001Z PUSH SW
S1310 QSW0683-001Z PUSH SW
WC800 QZW0112-001 WIRE CLAMP 21J,21EE,21A,
21UW,21UX,21
UG,11EE,11UW
,11UX,11UG,11
UH,11US
! Symbol No. Part No. Part Name Description Local
IC250 R2A15907SP-X KARAOKE IC
IC251 NJM4565E-X IC
IC500 MN101EF16Z-J11 MICON IC
! IC610 KIA7812API IC
! IC620 KIA7809API IC
! IC630 KIA278R09PI IC
! IC640 KIA278R05PI IC
! IC650 KIA7806API IC
IC920 MM1623XF-X IC
Q2800 KTC3203/OY/-T TRANSISTOR
Q4501 KTA1046/Y/ TRANSISTOR
Q4502 KTC3203/OY/-T TRANSISTOR
Q5301 RT1N141C-X DIGI TRANSISTOR
Q6601 KTC3203/OY/-T TRANSISTOR
Q6701 KTA1271/OY/-T TRANSISTOR
Q6702 RT1N140C-X DIGI TRANSISTOR
Q9700 RT6N430C-X TRANSISTOR
Q9701 RT6N430C-X TRANSISTOR
Q9710 RT6N430C-X TRANSISTOR
Q9711 RT6N430C-X TRANSISTOR
Q9720 RT1P140C-X DIGI TRANSISTOR
D2900 MA111-X SI DIODE
D2901 MA111-X SI DIODE
D4101 1N5402M-20 SI DIODE
D4102 1N5402M-20 SI DIODE
D4103 1N5402M-20 SI DIODE
D4104 1N5402M-20 SI DIODE
D4201 1N5402M-20 SI DIODE
D4202 1N5402M-20 SI DIODE
D4203 1N5402M-20 SI DIODE
D4204 1N5402M-20 SI DIODE
D4301 1N5402M-20 SI DIODE
D4302 1N5402M-20 SI DIODE
D4303 1N5402M-20 SI DIODE
D4304 1N5402M-20 SI DIODE
D4501 1N4003S-T5 SI DIODE
D4502 1N4003S-T5 SI DIODE
D4503 1N4003S-T5 SI DIODE
D4504 UDZW33B-X Z DIODE
D4506 UDZW6.2B-X Z DIODE
D5000 1N4003S-T5 SI DIODE
D5043 UDZW3.9B-X Z DIODE
D5099 UDZW5.1B-X SB DIODE
D5100 1N4003S-T5 SI DIODE
D5301 MA111-X SI DIODE
D5503 1N4003S-T5 SI DIODE
! Symbol No. Part No. Part Name Description Local
D5504 1N4003S-T5 SI DIODE
D6002 1N4003S-T5 SI DIODE
D6004 1N4003S-T5 SI DIODE
D6005 1N4003S-T5 SI DIODE
D6006 1N4003S-T5 SI DIODE
D6007 1N4003S-T5 SI DIODE
D6008 1N4003S-T5 SI DIODE
D6009 1N4003S-T5 SI DIODE
D6010 1N4003S-T5 SI DIODE
D6011 1N4003S-T5 SI DIODE
D6012 1N4003S-T5 SI DIODE
D6101 MTZJ13B-T2 Z DIODE
D6201 MTZJ13B-T2 Z DIODE
D6301 MTZJ13B-T2 Z DIODE
D6401 MTZJ6.2B-T2 Z DIODE
D6501 MTZJ6.2B-T2 Z DIODE
D6602 UDZW3.9B-X Z DIODE
D6701 MA111-X SI DIODE
C2500 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2501 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2503 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2504 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C2505 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2510 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2511 NCB31HK-681X C CAPACITOR 680pF 50V K
C2512 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2514 NCB31HK-681X C CAPACITOR 680pF 50V K
C2515 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2516 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2517 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2518 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2519 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2520 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2521 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2523 NCB31HK-471X C CAPACITOR 470pF 50V K
C2524 NCB31HK-471X C CAPACITOR 470pF 50V K
C2525 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2600 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2601 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2700 NCB31HK-152X C CAPACITOR 1500pF 50V K
C2701 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C2702 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2703 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2800 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2900 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2901 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2902 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2903 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2952 NCB31CK-104X C CAPACITOR 0.1uF 16V K
! C4101 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C4102 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C4103 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
! C4201 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C4202 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C4203 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
! C4301 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C4501 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C4502 QETN1JM-107Z E CAPACITOR 100uF 63V M
C4503 QETN2AM-476Z E CAPACITOR 47uF 100V M
C4504 QETN1HM-226Z E CAPACITOR 22uF 50V M
C4505 QETN1HM-226Z E CAPACITOR 22uF 50V M
C4506 NDC31HJ-101X C CAPACITOR 100pF 50V J
C4507 QETN1HM-106Z E CAPACITOR 10uF 50V M
C4511 QETN1HM-226Z E CAPACITOR 22uF 50V M
C4512 QETN1HM-226Z E CAPACITOR 22uF 50V M
C5012 NDC31HJ-200X C CAPACITOR 20pF 50V J
C5013 NDC31HJ-220X C CAPACITOR 22pF 50V J
C5017 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5018 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5037 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5091 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5117 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5191 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5199 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5303 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
! Symbol No. Part No. Part Name Description Local
