JVC DX-J36UN Service Manual

3-21
MICOM board (For J21 & J11 ver)
Block No. [0][4]
R5431 NRSA63J-394X MG RESISTOR 390k Ω 1/16W J
R5440 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5441 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R5450 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R6301 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6302 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6601 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R6701 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R6702 NRSA02J-152X MG RESISTOR 1.5k
Ω 1/10W J
R9202 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R9204 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R9206 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R9208 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R9210 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R9218 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R9221 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R9224 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R9227 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R9230 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R9232 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R9700 QRJ146J-681X UNF C RESISTOR 680
Ω 1/4W J
R9710 QRJ146J-681X UNF C RESISTOR 680
Ω 1/4W J
CN250 QGF1208F1-13 CONNECTOR FFC/FPC (1-13)
CN410 QGA7901C1-02 CONNECTOR W-B (1-2)
! CN420 QSW0812-001 VOLTAGE SWITCH 36UN,
36UX,
36UG,
36US,
36UW
CN430 QGD2504C1-04Z CONNECTOR (1-4)
CN500 QGF1036C2-13 CONNECTOR FFC/FPC (1-13)
CN501 QGF1208C1-21 CONNECTOR FFC/FPC (1-21)
CN502 QGF1036C2-28 CONNECTOR FFC/FPC (1-28)
CN503 QGF1208C1-15 CONNECTOR FFC/FPC (1-15)
CN504 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN505 QGF1208C1-23 CONNECTOR FFC/FPC (1-23)
CN506 QGF1208C1-21 CONNECTOR FFC/FPC (1-21)
CN507 QGF1208F1-11 CONNECTOR FFC/FPC (1-11)
CN508 QGF1210G1-05 CONNECTOR FFC/FPC (1-5)
CN630 QGA2501F1-03 CONNECTOR W-B (1-3)
CN931 QGF1208C1-15 CONNECTOR FFC/FPC (1-15)
EP401 E409182-001SM GRAND TERMINAL 36EE
FT411 QNG0003-001Z FUSE CLIP
FT412 QNG0003-001Z FUSE CLIP
FT415 QNG0003-001Z FUSE CLIP
FT416 QNG0003-001Z FUSE CLIP
FT417 QNG0003-001Z FUSE CLIP
FT418 QNG0003-001Z FUSE CLIP
FT421 QNG0003-001Z FUSE CLIP
FT422 QNG0003-001Z FUSE CLIP
FT425 QNG0003-001Z FUSE CLIP
FT426 QNG0003-001Z FUSE CLIP
FT427 QNG0003-001Z FUSE CLIP
FT428 QNG0003-001Z FUSE CLIP
FW400 QUM15B-35DGZ4-E FLAT WIRE
FW970 QUM025-19DGZ4-E FLAT WIRE
HS600 GV40762-001A HEAT SINK 36UW
J250 QNS0285-001 6.3 JACK
J251 QNS0285-001 6.3 JACK
J500 QNN0420-001 SURROUND JACK
J501 QNN0780-001 PIN JACK
J970 QNS0266-001 JACK
J980 QNZ0851-001 USB CONNECTOR
J9200 QNN0572-001 PIN JACK
J9300 QNN0557-002 PIN JACK
JS251 QSW1230-001 MIC ENCODER
K2702 NQR0022-003X FERRITE CHIP
K2703 QQR0621-001Z FERRITE BEADS
K2704 NQR0022-003X FERRITE CHIP
K2705 QQR0621-001Z FERRITE BEADS
K5000 QQR0621-001Z FERRITE BEADS
K9700 QQR0621-001Z FERRITE BEADS
K9710 QQR0621-001Z FERRITE BEADS
K9721 QQR0621-001Z FERRITE BEADS
K9800 NQR0022-003X FERRITE CHIP
K9801 NQR0022-003X FERRITE CHIP
K9802 QQR0621-001Z FERRITE BEADS
TW251 QUB130-14DMPP-E SIN TWIST WIRE
! Symbol No. Part No. Part Name Description Local
X5000 QAX0711-002Z CRYSTAL 8.000000MHz
! Symbol No. Part No. Part Name Description Local
IC250 R2A15907SP-X KARAOKE IC
IC251 NJM4565E-X IC
IC500 MN101EF16Z-J11 MICON IC
! IC610 KIA7812API IC
! IC620 KIA7809API IC
! IC630 KIA278R09PI IC
! IC640 PQ050RDC2SZF REGULATOR IC
! IC650 KIA7806API IC
IC920 MM1623XF-X IC
IC930 GP1FAV30TK0F OPT TRANSMITTER
Q2800 KTC3203/OY/-T TRANSISTOR
Q4501 KTA1046/Y/ TRANSISTOR
Q4502 KTC3203/OY/-T TRANSISTOR
Q5301 RT1N141C-X DIGI TRANSISTOR
Q6601 KTC3203/OY/-T TRANSISTOR
Q6701 KTA1271/OY/-T TRANSISTOR
Q6702 RT1N140C-X DIGI TRANSISTOR
Q9700 RT6N430C-X TRANSISTOR
Q9701 RT6N430C-X TRANSISTOR
Q9710 RT6N430C-X TRANSISTOR
Q9711 RT6N430C-X TRANSISTOR
Q9720 RT1P140C-X DIGI TRANSISTOR
D2900 MA111-X SI DIODE
D2901 MA111-X SI DIODE
D4101 1N5402M-20 SI DIODE
D4102 1N5402M-20 SI DIODE
D4103 1N5402M-20 SI DIODE
D4104 1N5402M-20 SI DIODE
D4201 1N5402M-20 SI DIODE
D4202 1N5402M-20 SI DIODE
D4203 1N5402M-20 SI DIODE
D4204 1N5402M-20 SI DIODE
D4301 1N5402M-20 SI DIODE
D4302 1N5402M-20 SI DIODE
D4303 1N5402M-20 SI DIODE
D4304 1N5402M-20 SI DIODE
D4501 1N4003S-T5 SI DIODE
D4502 1N4003S-T5 SI DIODE
D4503 1N4003S-T5 SI DIODE
D4504 UDZW33B-X Z DIODE
D4506 UDZW6.2B-X Z DIODE
D5000 1N4003S-T5 SI DIODE
D5043 UDZW3.9B-X Z DIODE
D5099 UDZW5.1B-X SB DIODE
D5100 1N4003S-T5 SI DIODE
D5301 MA111-X SI DIODE
D5503 1N4003S-T5 SI DIODE
D5504 1N4003S-T5 SI DIODE
D6002 1N4003S-T5 SI DIODE
D6004 1N4003S-T5 SI DIODE
D6005 1N4003S-T5 SI DIODE
D6006 1N4003S-T5 SI DIODE
D6007 1N4003S-T5 SI DIODE
D6008 1N4003S-T5 SI DIODE
D6009 1N4003S-T5 SI DIODE
D6010 1N4003S-T5 SI DIODE
D6011 1N4003S-T5 SI DIODE
D6012 1N4003S-T5 SI DIODE
D6101 MTZJ13B-T2 Z DIODE
D6201 MTZJ13B-T2 Z DIODE 21UN,21EE,
21A,21UW,2
1UX,21UG,1
1UN,11EE,11
UW,11UX,11
UG,11UH,11
US
! Symbol No. Part No. Part Name Description Local
