JVC DX-T99A - Page 109

3-43
Primary board (DX-T66)
Block No. [0][9]
R5021 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5022 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5023 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R5024 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5025 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5026 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R5027 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R5028 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R5029 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5030 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5035 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R5036 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R5037 QRE141J-560Y C RESISTOR 56 Ω 1/4W J
R5038 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5039 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5040 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5041 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5042 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R5043 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R5044 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
R5045 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R5046 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R5050 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6321 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6342 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6352 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6356 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6357 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6358 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6501 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
R6502 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
R6503 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
R6510 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R6511 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R6512 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R6513 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6514 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6516 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R6517 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R6518 QRJ146J-681X UNF C RESISTOR 680 Ω 1/4W J
R6519 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6520 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R6521 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R6522 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R6523 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R6524 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6526 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R6527 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R6528 QRJ146J-681X UNF C RESISTOR 680 Ω 1/4W J
R6529 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R6530 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R6531 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R6532 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R6533 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6534 QRJ146J-100X UNF C RESISTOR 10
Ω 1/4W J
R6536 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R6537 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R6538 QRJ146J-681X UNF C RESISTOR 680 Ω 1/4W J
R6539 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6601 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R6602 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R6603 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6604 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 R6605 QRJ146J-150X UNF C RESISTOR 15 Ω 1/4W J
R6606 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6607 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 R6608 QRJ146J-150X UNF C RESISTOR 15 Ω 1/4W J
R6701 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R6702 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R6703 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6704 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R6705 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R6706 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6801 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R6802 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R6803 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R6804 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
 R6805 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
R6806 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
R6911 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6912 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R6921 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6922 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R6931 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R6932 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
L6511 QQLZ035-R39 COIL 0.39uH
L6521 QQLZ035-R39 COIL 0.39uH
L6531 QQLZ035-R39 COIL 0.39uH
CN500 QGF1036F2-19 CONNECTOR FFC/FPC (1-19)
CN601 QGB2510K2-09 CONNECTOR B-B (1-9)
CN602 QGF1205C2-13 CONNECTOR FFC/FPC (1-13)
CN603 QGF1205F2-11 CONNECTOR FFC/FPC (1-11)
CN604 QGA2501F1-03 CONNECTOR W-B (1-3)
CN651 QGB2510K2-13 CONNECTOR B-B (1-13)
CN652 QGF1205C2-08 CONNECTOR FFC/FPC (1-8)
FL500 QLF0150-001 FL TUBE
FW500 QUM153-18DGZ4-E FLAT WIRE
S5000 QSW0683-001Z PUSH SW I.M
S5001 QSW0683-001Z PUSH SW I.M
S5002 QSW0683-001Z PUSH SW I.M
S5003 QSW0683-001Z PUSH SW I.M
S5004 QSW0683-001Z PUSH SW I.M
S5005 QSW0683-001Z PUSH SW I.M
S5006 QSW0683-001Z PUSH SW I.M
S5007 QSW0683-001Z PUSH SW I.M
S5008 QSW0683-001Z PUSH SW I.M
S5009 QSW0683-001Z PUSH SW I.M
S5010 QSW0683-001Z PUSH SW I.M
S5011 QSW0683-001Z PUSH SW I.M
S5012 QSW0683-001Z PUSH SW I.M
S5013 QSW0683-001Z PUSH SW I.M
S5014 QSW0683-001Z PUSH SW I.M
S5015 QSW0683-001Z PUSH SW I.M
S5016 QSW0683-001Z PUSH SW I.M
S5017 QSW0683-001Z PUSH SW I.M
S5018 QSW0683-001Z PUSH SW I.M
S5019 QSW0683-001Z PUSH SW I.M
S5020 QSW0683-001Z PUSH SW I.M
S5021 QSW0683-001Z PUSH SW I.M
S5022 QSW0683-001Z PUSH SW I.M
S5023 QSW0683-001Z PUSH SW I.M
S5024 QSW0683-001Z PUSH SW I.M
S5025 QSW0683-001Z PUSH SW I.M
S5026 QSW0683-001Z PUSH SW I.M
S5027 QSW0683-001Z PUSH SW I.M
S5028 QSW0683-001Z PUSH SW I.M
S5029 QSW0683-001Z PUSH SW I.M
S5030 QSW0683-001Z PUSH SW I.M
S5031 QSW0683-001Z PUSH SW I.M
S5032 QSW0683-001Z PUSH SW I.M
S5033 QSW0683-001Z PUSH SW I.M
S5034 QSW0683-001Z PUSH SW I.M
SP500 GV40205-004A IC HOLDER
 Symbol No. Part No. Part Name Description Local
C1002 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1003 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1004 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C1005 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1013 QFZ0228-104Z M CAPACITOR 0.1uF
C1014 QFZ0228-104Z M CAPACITOR 0.1uF
C1015 QFZ0228-104Z M CAPACITOR 0.1uF
C1016 QETM2CM-226 E CAPACITOR 22uF 160V M
 Symbol No. Part No. Part Name Description Local
