1-2 (No.MB353)
SPECIFICATION
Designs and Specifications are subject to change without notice.
Amplifier section Output Power 90 W per channel, min. RMS, driven into 6Ω at 1 kHz with no more than 10% total harmonic
distortion.
Speakers Impedance 6Ω - 16Ω
Audio Input AUX:400 mV/50 kΩ
USB:USB Ver. 1.1
Tuner section FM tuning range 87.5 MHz - 108.0 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player section Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
General Power requirement AC 120 V , 60 Hz
Power consumption 125 W (at operation)
21 W (on standby)
0.8 W (with deactivating the clock indication)
Dimensions (approx.) 175 mm × 232 mm × 412 mm (W/H/D)
Mass (approx.) 6.6 kg
Speakers Type 2-way Bass reflex
Speaker units Woofer:10 cm cone × 1
Tweeter:4 cm cone × 1
Impedance 6Ω
Dimensions (approx.) 144 mm × 231 mm × 201 mm (W/H/D)
Mass (approx.) 2.0 kg each
