JVC FS-SD7 Schematic Diagrams

FS-SD5/FS-SD7/FS-SD9
3-5
Item
Parts number Parts name Area
Parts list
Q'ty
Description
Block No. M1MM
81 LV31683-005A
FUNC BTN ASSY
1
FS-SD9
LV31683-004A
FUNC BTN ASSY
1
FS-SD5/SD7
82 QYSBST3006Z
T.SCREW
4
GEAR.B+BOTTOM
83 QYSDSF2606Z
SCREW
2
JACK PWB+TOP
84 LV30064-008A
SPACER
1
86 QYSBST3006Z
T.SCREW
3
MOTER.B+BOTTOM.
87 LV30226-015A
SPACER
1
88 LV41826-001A
SHIELID(A)
1
89 LV41827-001A
SHIELD(R)
1
90 LV41524-001A
MAIN GEAR
1
POM
91 LV31689-002A
SHAFT 1
1
SUS
92 QYREE6000X
E RING
2
93 QYSPSPG3006Z
SCREW
2
SAFT 1+G.BASE
94 LV30064-075A
SPACER
2
97 QYSBST3006Z
T.SCREW
4
BOTTOM.C+TOP
98 QYSSST3006Z
SCREW
3
BOTTOM+FRONT.P
99 QMF51E2-5R0-J1
FUSE
1
F1902
100 QMF51E2-3R15-J1
FUSE
1
F1903
101 QMF51E2-1R0-J1
FUSE
1
F1901
102 QQT0286-004
POWER TRANSF
1
T1901
108 QYSBST3006Z
T.SCREW
1
BOTTOM.C+AMP PW
109 QYSDSF2606Z
SCREW
6
BOTTOM+G.BASE
110 QUQB12-0905DJ
FFC WIRE
1
111 QUQB12-0806CJ
FFC WIRE
1
112 WJM0133-001A
E-SI C WIRE C-F
1
113 QUQB12-1805DJ
FFC WIRE
1
115 LV41772-001A
CAUTION LABEL
1
REAR PANEL
116 LV31865-001A
HOLDER
1
S1901
117 QYSBSF3008Z
SCREW
1
S1901
(General assenbly)
