FS-SD5/FS-SD7/FS-SD9
3-8
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
Q
1914 2SA1037AK/R/-X TRANSISTOR TU5
Q
1915 2SC2412K/R/-X TRANSISTOR TU5
Q
3101 2SD2114K/VW/-X CHIP TR.C.M S.MUTE
Q
3201 2SD2114K/VW/-X CHIP TR.C.M S.MUTE
Q
3301 DTA143TKA-X TRANSISTOR S.MUTE BUFF
Q
8001 DTC114TKA-X TRANSISTOR
Q
8002 DTC114EKA-X TR
Q
8003 DTA114EKA-X DIGITAL.TRANSIS
Q
8101 2SD2114K/VW/-X CHIP TR.C.M
Q
8201 2SD2114K/VW/-X CHIP TR.C.M
R 1 NRSA02J-102X MG RESISTOR
R 2 NRSA02J-821X MG RESISTOR
R 12 NRSA02J-102X MG RESISTOR
R 13 NRSA02J-104X MG RESISTOR
R 20 NRSA02J-331X MG RESISTOR
R 21 NRSA02J-224X MG RESISTOR
R 22 NRSA02J-331X MG RESISTOR
R 23 NRSA02J-270X MG RESISTOR
R 24 NRSA02J-271X MG RESISTOR
R 25 NRSA02J-473X MG RESISTOR
R 27 NRSA02J-223X MG RESISTOR
R 29 NRSA02J-473X MG RESISTOR
R 30 NRSA02J-103X MG RESISTOR
R 31 NRSA02J-103X MG RESISTOR
R 32 NRSA02J-473X MG RESISTOR
R 34 NRSA02J-333X MG RESISTOR
R 35 NRSA02J-333X MG RESISTOR
R 36 NRSA02J-103X MG RESISTOR
R 37 NRSA02J-472X MG RESISTOR
R 38 NRSA02J-392X MG RESISTOR
R 39 NRSA02J-392X MG RESISTOR
R 42 NRSA02J-102X MG RESISTOR
R 43 NRSA02J-102X MG RESISTOR
R 44 NRSA02J-102X MG RESISTOR
R 45 NRSA02J-102X MG RESISTOR
R 46 NRSA02J-473X MG RESISTOR
R 48 NRSA02J-102X MG RESISTOR
R 52 NRSA02J-472X MG RESISTOR
R 54 NRSA02J-472X MG RESISTOR
R 55 NRSA02J-182X MG RESISTOR
R 56 NRSA02J-332X MG RESISTOR
R 57 NRSA02J-102X MG RESISTOR
R 66 NRSA02J-222X MG RESISTOR
R 68 NRSA02J-223X MG RESISTOR
R 69 NRSA02J-222X MG RESISTOR
RY191 QSK0116-001 RELAY
R1101 NRSA02J-122X MG RESISTOR TU
R1102 NRSA02J-562X MG RESISTOR TU
R1103 NRSA02J-103X MG RESISTOR AHB
R1104 NRSA02J-332X MG RESISTOR LPF
R1105 NRSA02J-272X MG RESISTOR FS-SD7/SD9
R1105 NRSA02J-392X MG RESISTOR FS-SD5
R1106 NRSA02J-152X M.G.RESISTOR FS-SD5
R1106 NRSA02J-392X MG RESISTOR FS-SD7/SD9
R1107 NRSA02J-153X MG RESISTOR AHB
R1108 NRSA02J-302X MG RESISTOR FS-SD5
R1108 NRSA02J-432X MG RESISTOR FS-SD7/SD9
R1109 NRSA02J-153X MG RESISTOR AHB
R1110 NRSA02J-224X MG RESISTOR FS-SD7/SD9
R1110 NRSA02J-184X MG RESISTOR FS-SD5
R1111 NRSA02J-103X MG RESISTOR AHB
R1112 NRSA02J-332X MG RESISTOR HP
R1113 NRSA02J-563X MG RESISTOR HP
R1114 NRSA02J-102X MG RESISTOR HP
R1115 NRSA02J-561X MG RESISTOR HP
R1116 NRSA02J-222X MG RESISTOR HP.MUTE
R1201 NRSA02J-122X MG RESISTOR TU
R1202 NRSA02J-562X MG RESISTOR TU
R1203 NRSA02J-103X MG RESISTOR AHB
R1204 NRSA02J-332X MG RESISTOR LPF
R1205 NRSA02J-272X MG RESISTOR FS-SD7/SD9
R1205 NRSA02J-392X MG RESISTOR FS-SD5
R1206 NRSA02J-152X M.G.RESISTOR FS-SD5
R1206 NRSA02J-392X MG RESISTOR FS-SD7/SD9
R1207 NRSA02J-153X MG RESISTOR AHB
R1208 NRSA02J-302X MG RESISTOR FS-SD5
R1208 NRSA02J-432X MG RESISTOR FS-SD7/SD9
R1209 NRSA02J-153X MG RESISTOR AHB
R1210 NRSA02J-224X MG RESISTOR FS-SD7/SD9
R1210 NRSA02J-184X MG RESISTOR FS-SD5
R1211 NRSA02J-103X MG RESISTOR AHB
R1212 NRSA02J-332X MG RESISTOR HP
R1213 NRSA02J-563X MG RESISTOR HP
R1214 NRSA02J-102X MG RESISTOR HP
R1215 NRSA02J-561X MG RESISTOR HP
R1216 NRSA02J-222X MG RESISTOR HP.MUTE
R1301 NRSA02J-513X MG RESISTOR AHB
R1302 NRSA02J-471X MG RESISTOR AHB
R1303 NRSA02J-102X MG RESISTOR AHB
R1304 NRSA02J-224X MG RESISTOR FS-SD7/SD9
R1304 NRSA02J-154X MG RESISTOR FS-SD5
R1305 NRSA02J-124X MG RESISTOR AHB
R1306 NRSA02J-513X MG RESISTOR FS-SD5
R1306 NRSA02J-563X MG RESISTOR FS-SD7/SD9
R1307 NRSA02J-912X MG RESISTOR HP
R1308 NRSA02J-103X MG RESISTOR HP
R1309 NRSA02J-100X MG RESISTOR HP
R1310 NRSA02J-102X MG RESISTOR HP.MUTE.D
R1311 NRSA02J-102X MG RESISTOR S.MUTE.D
R1312 NRSA02J-471X MG RESISTOR
R1313 NRSA02J-471X MG RESISTOR
R1801 NRSA02J-471X MG RESISTOR M.DRIVER
R1802 NRSA02J-153X MG RESISTOR M.DRIVER
R1803 NRSA02J-473X MG RESISTOR M.DRIVER
R1804 NRSA02J-100X MG RESISTOR M.DRIVER
R1805 NRSA02J-100X MG RESISTOR M.DRIVER
R1806 NRSA02J-183X MG RESISTOR M.DRIVER
R1807 NRSA02J-471X MG RESISTOR
R1808 NRSA02J-471X MG RESISTOR
R1902 NRSA02J-1R0X MG RESISTOR SW10
R1903 NRSA02J-1R0X MG RESISTOR SW10
R1904 NRSA02J-1R0X MG RESISTOR SW10
R1905 NRSA02J-151X MG RESISTOR SW10
R1906 NRSA02J-102X MG RESISTOR SW10
R1907 NRSA02J-102X MG RESISTOR SW10
R1908 NRSA02J-102X MG RESISTOR SW10
R1909 NRSA02J-102X MG RESISTOR SW10
R1910 NRSA02J-472X MG RESISTOR SW10
R1911 NRSA02J-471X MG RESISTOR SW10
R1912 NRSA02J-561X MG RESISTOR SW10
R1913 NRSA02J-272X MG RESISTOR SW10
R1914 NRSA02J-471X MG RESISTOR SW10
R1915 NRSA02J-822X MG RESISTOR SW10
R1916 NRSA02J-102X MG RESISTOR SW10
R1917 NRSA02J-122X MG RESISTOR SW10
R1918 NRSA02J-153X MG RESISTOR SW10
(Main board)
Item
Parts number Parts name Area
Remarks
