FS-SD5/FS-SD7/FS-SD9
3-11
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
D6063 1SS355-X DIODE
D7001 1SS133-T2 SI DIODE
D7002 1SS133-T2 SI DIODE
D7003 1SS133-T2 SI DIODE
D7004 1SS133-T2 SI DIODE
D7005 1SS133-T2 SI DIODE
D7006 1SS133-T2 SI DIODE
D7007 MTZJ5.1C-T2 ZENER DIODE
D7008 1SS133-T2 SI DIODE
D7009 MTZJ8.2B-T2 DIODE
D7010 1SS355-X DIODE
IC501 BD3861FS-X IC FUNC/VOL
IC601 AN8806SB-W IC
IC602 LA6541-X IC
IC603 MN35510 IC
IC701 UPD780024AGKA11 IC(MCU)
IC702 KIA78S06P-T IC
J5301 QNS0047-001 JACK LINE IN
J5302 QNS0047-001 JACK LINE OUT
J5303 QNN0198-001 1PIN PINJ BLACK S.W. OUT
J6001 GP1FA550TZ OPT TRANSMITTER
K5302 QQR0779-001Z INDUCTOR DG
K6051 QQR0601-001Z FERRITE BEADS
K7001 QQR0601-001Z FERRITE BEADS
L7001 QQL01BK-100Z INDUCTOR
L7002 QQL01BK-100Z INDUCTOR
Q
5101 2SD2114K/VW/-X CHIP TR.C.M L/O MUTE
Q
5201 2SD2114K/VW/-X CHIP TR.C.M L/O MUTE
Q
5301 DTA114EKA-X DIGITAL.TRANSIS L/O MUTE.D
Q
5302 2SD2114K/VW/-X CHIP TR.C.M S.W.MUTE
Q
6001 2SA1037AK/R/-X TRANSISTOR
Q
6031 2SC2060/QR/-T TRANSISTOR
Q
7001 2SC2668/O/-T TRANSISTOR
Q
7002 2SC2668/O/-T TRANSISTOR
Q
7003 DTA114TKA-X DIGITAL.TR
Q
7004 2SC2412K/R/-X TRANSISTOR
Q
7006 2SC2412K/R/-X TRANSISTOR
Q
7007 DTC114EKA-X TR
Q
7008 DTA114EKA-X DIGITAL.TRANSIS
Q
7009 2SA1037AK/R/-X TRANSISTOR
Q
7010 DTC144EKA-X TRANSISTOR
Q
7011 2SA1037AK/R/-X TRANSISTOR
R5101 NRSA02J-223X MG RESISTOR LINE IN
R5102 NRSA02J-683X MG RESISTOR LINE IN
R5103 NRSA02J-302X MG RESISTOR CD IN
R5104 NRSA02J-182X MG RESISTOR FUC.OUT
R5105 NRSA02J-473X MG RESISTOR LINE OUT
R5106 NRSA02J-392X MG RESISTOR LINE OUT
R5107 NRSA02J-102X MG RESISTOR LINE OUT
R5108 NRSA02J-222X MG RESISTOR L/O MUTE
R5109 NRSA02J-563X MG RESISTOR S.W.OUT
R5110 NRSA02J-332X MG RESISTOR BASS
R5201 NRSA02J-223X MG RESISTOR LINE IN
R5202 NRSA02J-683X MG RESISTOR LINE IN
R5203 NRSA02J-302X MG RESISTOR CD IN
R5204 NRSA02J-182X MG RESISTOR FUC.OUT
R5205 NRSA02J-473X MG RESISTOR LINE OUT
R5206 NRSA02J-392X MG RESISTOR LINE OUT
R5207 NRSA02J-102X MG RESISTOR LINE OUT
R5208 NRSA02J-222X MG RESISTOR L/O MUTE
R5209 NRSA02J-563X MG RESISTOR S.W.OUT
R5210 NRSA02J-332X MG RESISTOR BASS
R5301 NRSA02J-223X MG RESISTOR L/O MUTE D
R5302 NRSA02J-222X MG RESISTOR S.W.MUTE
R5303 NRSA02J-473X MG RESISTOR S.W.OUT
R5304 NRSA02J-102X MG RESISTOR S.W.OUT
R5305 NRSA02J-1R5X MG RESISTOR VCC
R6001 NRSA02J-123X MG RESISTOR
R6002 NRSA02J-225X MG RESISTOR
R6003 NRSA02J-102X MG RESISTOR
R6005 NRSA02J-274X MG RESISTOR
R6006 NRSA02J-473X MG RESISTOR
R6007 NRSA02J-273X MG RESISTOR
R6008 NRSA02J-564X MG RESISTOR
R6009 NRSA02J-563X MG RESISTOR
R6010 NRSA02J-104X MG RESISTOR
R6012 NRSA02J-103X MG RESISTOR
R6013 NRSA02J-121X MG RESISTOR
R6014 NRSA02J-100X MG RESISTOR
R6015 NRSA02J-120X MG RESISTOR
R6016 NRSA02J-910X MG RESISTOR
R6021 NRSA02J-151X MG RESISTOR
R6022 NRSA02J-151X MG RESISTOR
R6023 NRSA02J-151X MG RESISTOR
R6024 NRSA02J-154X MG RESISTOR
R6025 NRSA02J-154X MG RESISTOR
R6026 NRSA02J-393X MG RESISTOR
R6027 NRSA02J-393X MG RESISTOR
R6028 NRSA02J-393X MG RESISTOR
R6029 NRSA02J-393X MG RESISTOR
R6031 NRSA02J-681X MG RESISTOR
R6032 NRSA02J-681X MG RESISTOR
R6040 NRSA02J-102X MG RESISTOR
R6041 NRSA02J-433X MG RESISTOR
R6042 NRSA02J-472X MG RESISTOR
R6043 NRSA02J-123X MG RESISTOR
R6044 NRSA02J-683X MG RESISTOR
R6045 NRSA02J-433X MG RESISTOR
R6046 NRSA02J-0R0X MG RESISTOR
R6047 NRSA02J-332X MG RESISTOR
R6048 NRSA02J-222X MG RESISTOR
R6049 NRSA02J-152X MG RESISTOR
R6050 NRSA02J-332X MG RESISTOR
R6051 NRSA02J-102X MG RESISTOR
R6052 NRSA02J-102X MG RESISTOR
R6053 NRSA02J-102X MG RESISTOR
R6054 NRSA02J-102X MG RESISTOR
R6056 NRSA02J-0R0X MG RESISTOR
R6057 NRSA02J-0R0X MG RESISTOR
R6058 NRSA02J-0R0X MG RESISTOR
R6059 NRSA02J-471X MG RESISTOR
R6060 NRSA02J-471X MG RESISTOR
R6061 NRSA02J-104X MG RESISTOR
R6063 NRSA02J-124X MG RESISTOR
R6064 NRSA02J-681X MG RESISTOR
R6066 NRSA02J-220X MG RESISTOR
R6067 NRSA02J-220X MG RESISTOR
R6068 NRSA02J-220X MG RESISTOR
R6069 NRSA02J-155X MG RESISTOR
R6071 NRSA02J-102X MG RESISTOR
R6072 NRSA02J-102X MG RESISTOR
R6080 NRSA02J-0R0X MG RESISTOR
R6081 NRSA02J-0R0X MG RESISTOR
R6082 NRSA02J-392X MG RESISTOR
R6083 NRSA02J-0R0X MG RESISTOR FS-SD7
R6121 NRSA02J-151X MG RESISTOR
(CD board)
Item
Parts number Parts name Area
Remarks
