Removing the fan motor assembly
(See Fig.24 and 25)
- Prior to performing the following procedure, remove
the CD mechanism base assembly.
1. Disconnect the harness from connector CN181 on
the main board.
2. Remove the two screws P_ on the left side of the
body. Move the fan motor assembly upward to
remove
it
from
the
base
chassis.
Man
bard
Fan motor
3. Remove the two screws Q and the fan motor from Pp
the fan bracket.
Fan bracket
™@ Removing the main board (See Fig.26)
: Prior to performing the following procedure, remove
the CD mechanism base assembly and the door arm
assembly.
‘ To facilitate operation process, remove the gear
motor assembly before performing the following Fan motor
rocedure.
P Fig.25
1. Disconnect the harnesses from connector CN102,
CN106, CN191, CN192, CN193 and CN181 on the
main board. R Gear motor assembly
CN191 CN193 Main board
2. Remove the five screws R attaching the main board
with the cord clamp.
<Front panel assembly>
@Removing the front panel board
(See Fig.27)
CN192| CN181
* Prior to performing the following procedure, remove FR -oNiee cae
the front panel assembly.
Fig.26
1. Remove the seven screws S_ attaching the front
panel board inside the front panel assembly.
S Front panel assembly S
Fig.27
