JVC FS-SD9R Service Manual

Using the Timers
Setting the SLEEP Timer
(Using the Remote Control)
Use the Sleep Timer to tum the System off after a cenain
number of minutes when it is playing. By setting the Sleep
‘Timer. you can falt asleep to music and know that your Sys-
tem will cum off by itself rather than play all night.
WW You can only set the Sleep Timer when the System is on
and a source is playing.
1 Play a CD or tune in to the desired sta-
tion.
2 Press the SLEEP button on the Remote
Control.
‘The “SLEEP” indicator lights up.
When the clock is not set, “CLOCK” and “ADJUST”
appear altemately on the display. Set the clock at first
3 Set the length of time you want the
source to play before shutting off.
+ Rach time you press the SLEEP button, it changes
the number of minutes shown on the display in this
sequence
10 + 20 ~ 30 ~ 60 - 90 + 120 ~ Cancelled —
(back to the beginning)
The selected number of minutes for the Sleep Timer will
stop blinking five seconds later and the display returns to
the original one before setting the Steep Timer. (The display
is dimmed.)
‘The System is now set to tum off after the number of min-
utes you set.
To Confirm the Sleep Time:
When the SLEEP button is pressed, the remaining sleep
time is displayed. Wait until the display retums to the orig-
inal display.
To Cancel the SLEEP Timer Setting:
Press the SLEEP button until the “SLEEP” indicator goes
out on the display.
‘Tuming off the System also cancels the SLEEP Timer.
Ifyou are setting the Daily Timer, the System will be
lurned on at the set time to wake you up.
22
Troubleshooting
* Ifyou cannot solve the problem from the hints given
here. o the System has been physically damaged, call a
qualified person. such as your dealer, for service.
» Ifyou are having a problem with your System, check this
list for a possible solution before calling for service.
‘Symptom Possible Cause Action
No sound is heard. * Connections are incorrect, or loose: * Check all connections and make cor-
rections. (See pages 4 to 8.)
* Headphones are connected. + Disconnect the headphones.
Poor radio reception * The antenna is disconnected. + Reconnect the antenna securely.
* The AM Loop Antenna is too close. + Change the position and direction of
to the System. the AM Loop Antenna.
* The FM Wire Antenna is not prop- + Extend FM Wire Antenna to the best
erly extended and positioned. reception position,
The CD skips. The CD is dirty or scratched Clean oF replace the CD.
The CD does not play.
‘The CD is upside down.
Put the CD in with the label side up.
Unable to operate the Remote Control.
+ The path between the Remote Con-
trol and the sensor on the Unit is
blocked,
‘+ The batteries have lost their charge
+ Remove the obstruction.
+ Replace the batteries
Operations are disabled.
‘The built-in microprocessor has mal-
functioned due to extemal electrical in-
terference.
Unplug the System then plug it back in
after a few minutes.
FS-SD5R/FS-SD7R/FS-SD9R
Care And Maintenance
Handle your CDs carefully, and they will last a long time.
Only CDs bearing this mark can
be used with this System. How-
ever, continued use of imegular
shape CDs theart-shape, octago-
nal. etc.) can damage the System
Remove the CD from its case by
holding it at the edges while
pressing the case's center hole
lightly.
+ Do not touch the shiny surface of
the CD. or bend the CD.
Put the CD back in its case afler
use to prevent warping
Be careful not to scratch the sur-
face of the CD when placing it
back in the case.
Avoid exposure to direct sunlight.
temperature extremes, and mois-
ture.
* A dirty CD may not play cor-
rectly. [fa CD does become ditty,
wipe it with a soft cloth ina
) straight line from center to edge.
4a CAUTION:
* Do not use any solvent (for example, con-
ner, spray thinner,
ventional record ch
benzine, etc.) to clean a CD.
General Notes
In general. you will have the best performance by keeping
your CDs and the mechanism clean
+ Store CDs in their cases, and keep them in cabinets oron
shelves.
+ Keep the System's Top Cover closed when not in use
Ay oY-vethicer-]arelat-y
Cleaning the Lens
if the lens in the CD pickup is dirty. dropout, ete., could de~
grade sound
Open the Top Cover and clean the lens as shown.
+ Use a blower (available from a camera store) 10 blow
dust off the lens.
* [ether are fingerprints, etc. on the tens, gently wipe
clean with a cotton swab.
Moisture Condensation
Moisture may condense on the lens
inside the System in the following
cases:
G + After turing on heating in the
4 room
+ Inadamp wam.
* Ifthe Sysiem is brought directly
from a cold to a warm place.
Should this occur, the System may
malfunction. In this case, leave the
System tumed on fora few hours un-
{il the moisture evaporates, unplug
the AC power cord, and then plug it
in again.
Amplifier
Output Power
Input Sensitivity/Impedance (1 kHz)
MD/AUX IN
Output Sensitivity/Impedance (1 kHz)
MD/AUX OUT
CD DIGITAL. OUT (Optical out)
Speaker terminals
Subwoofer out
Phones
CO Player
Signal-To-Noise Ratio
Wow And Flutter
Tuner
FM Tuner
Tuning Range
AM Tuner
‘Tuning Range
Center Unit (FS-SD5R/SD7R/SD9R)
Dimensions
Mass.
Speaker Specifications (each gai
FS-SD!
Speakers
Impedance
Dimensions
Mass
FS-SD7R
Speakers
Impedance
Dimensions
Mass
FS-SOSR
Speakers
Impedance
Dimensions
Mass
Accessories
Power Specifications
Power Requirements
Power Consumption
38 W (19 W + 19 W) at 4 ohms (Max.)
30 W (1S W + 15 W)at 4 ohms (10% THD)
500 mV/47 kohms.
500 mV/S kohms
~21 dBm - -15 dBm
4- 16 ohms
230m V/19kohms
16 ohms - | kohm
0 - 18 mW/ch output into 32 ohms
90 dB
Unmeasurable
87.5 MHz - 108.0 MHz
(MW) S22 kilz ~ 1, 629kH2z
(LW) 144 kHz — 288kHz
300mm X 75mm x 215mm (W/H/D}
Approx. 3.0kg
8 cm cone
4 ohms
100mm x 186mm X 193.Smm (W/H/D)
1 Skg
8 cm cone
4 obms
137mm X 23tmm x 14)mm (W/H/D)
Lake
8 cm cone
4 ohms
135mm X 231mm X 141mm (W/H/D)
Lake
Power Cord (1)
AM Loop Antenna (1)
Remote Control (1)
Batteries R6P (SUM-3)/AA (L5F) (2)
FM Wire Antenna (1)
Speaker Cords (2)
Spacers (6) (only for FS-SD7R/SDOR)
AC 230V ~ . S0Hz
25 watts (power on mode}
1.9 watts (in Standby mode}
Design and specifications are subject to change without notice.
JVC
VICTOR COMPANY OF JAPAN, LIMITED.
G2EN
@ o200mnmcREusc
1-11
;
|
|
§
|
|
