Specifications
EN
Specifications of the VGA IN terminal
Pin No. Signal name Pin No. Signal name
1
Red
2
Green
3
Blue
4
—
5
GND
6
GND
7
GND
8
9
10
11
12
13
14
15
External
GND
+5 V
GND
—
DDC Data
HD
VD
DDC Clock
GND
Pin No. Signal name Pin No. Signal name Pin No. Signal name
1
T.M.D.S Data 2–
9
T.M.D.S Data 1–
17
T.M.D.S Data 0–
2
T.M.D.S Data 2+
10
T.M.D.S Data 1+
18
T.M.D.S Data 0+
3
T.M.D.S Data 2
shield
11
T.M.D.S Data 1
shield
19
T.M.D.S Data 0
shield
4
NC
12
NC
20
NC
5
NC
13
NC
21
NC
6
DDC Clock
14
+5 V Power
22
T.M.D.S Clock shield
7
DDC Data
15
GND
23
T.M.D.S Clock+
8
NC
16
Hot Plug Detect
24
T.M.D.S Clock–
Specifications of the DVI-D terminal
GD-W213L
Screen Size 21.5 inches (Diagonal 546.9 mm)
Resolution 1920 pixels × 1080 pixels
Pixel Pitch 0.248 mm × 0.248 mm
Brightness (typ.)
Contrast Ratio (typ.)
Aspect Ratio
Viewing Angle (H/V) (typ.)
Display Color
Response Time
Audio output
Outline Dimension (W×H×D) 509.8 mm × 351.6 mm × 190 mm
Operation Temperature
Operation humidity
250 cd/m
2
1000 : 1
16 : 9
170°/ 160°
16.7 million
5 ms
0.5 W + 0.5 W
AC 100 V – 240 V , 50 Hz / 60 Hz
0.47 A
0 ℃
- 40 ℃
20%
- 80 % (non-condensing)
Accessories Power cord x 2 pcs
*For United Kingdom(1.8 m) x 1pcs
*For European countries(1.8 m) x 1pcs
VGA cable x1pcs
Audio cable x1pcs
3.5 kg
Weight
Power requirements
Ratedinput current
Model Name
