The following table indicate different parts number between models GR-AX940U, AX940UC, AX840U, AX840UC, AX640U and
GR-AX640UC.
PACKING ASSEMBLY <M1>
2 PACKING CASE LY30905-018A LY30905-039A LY30905-011A LY30905-021A LY30905-017A LY30905-020A
5 INST. BOOK (EN) LYT0259-001A LYT0251-001A LYT0255-001B
7 REGIST. CARD BT-51006-1 – BT-51006-1 – BT-51006-1 –
13 WARRANTY CARD – BT-52002-1 – BT-52002-1 – BT-52002-1
14 INST. BOOK (FR) – LYT0321-001A – LYT0286-001A – LYT0286-001A
15 SER. NET CARD – BT-20071B – BT-20071B – BT-20071B
GR-AX940U GR-AX940UC GR-AX840U GR-AX840UC GR-AX640U GR-AX640UC
MODEL
ITEM
REF No.
FINAL ASSEMBLY <M2>
101 LOWER CASE ASSY LY10122-009B LY10122-008B
106 FRONT COVER ASSY LY10124-010C LY10124-005C LY10124-005D LY10124-004C
106R COVER (LIGHT) – – LY30934-004A LY30934-003A
107 CASSETTE COVER ASSY LY10126-002A LY10126-001A
108 BUTTON (PUSH) ASSY LY30899-002B LY30899-002B LY30899-001B
110 TOP COVER LY10129-016B LY10129-009B LY10129-015B
116 DC LIGHT ASSY LY30860-001A ––––
116A LAMP YQ44266 ––––
137 FRAME ASSY LY20372-001A LY20372-002A
137F CONTACT (LIGHT),X2 YQ43810 ––––
137G E-SI C WIRE C-F WJM0003-003A ––––
146 KNOB (LIGHT) LY41083-001B ––––
GR-AX940U GR-AX940UC GR-AX840U GR-AX840UC GR-AX640U GR-AX640UC
MODEL
ITEM
REF No.
ELECTRONIC VIEWFINDER ASSEMBLY <M4>
360 EVF ASSY LYH20038-002A ––
381 EVF ASSY – – – – LY20374-001A
GR-AX940U GR-AX940UC GR-AX840U GR-AX840UC GR-AX640U GR-AX640UC
MODEL
ITEM
REF No.
MAIN BOARD ASSEMBLY <01>
PW MAIN BOARD ASSY YB10243UC-01 YB10243UB-02 YB10243UA-02
IC3103 IC – – – – NJM2535V
IC4006 IC TMS4C2973-28-X ––––
IC6002 IC MM1257AM ––
IC7101 IC (DIGITAL) TC7SET02FU ––
IC7102 IC (DIGITAL) TC7SET08FU ––
Q2061 TRANSISTOR 2SC4617/QR/-X –––`–
GR-AX940U GR-AX940UC GR-AX840U GR-AX840UC GR-AX640U GR-AX640UC
MODEL
ITEM
REF No.
Note: Mark – is not used. Mark is same as left.
