JVC GR-AX640U User Manual

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽
E. VF BOARD ASSEMBLY (GR-AX640U/UC) <60>
PW LY41289-001A VF BOARD ASSY
IC7001 BA7149F-XE IC
Q7001 2SD968A(RS) PH TRANSISTOR
Q7002 2SA1748(QR) PH TRANSISTOR
Q7003 2SA1748(QR) PH TRANSISTOR
D7001 MA142WA DIODE
R7002 NRSA02J-3R9X MG RESISTOR 3.9Ω,1/10W
R7003 NRVA02D-153X CMF RESISTOR 15kΩ,1/10W
R7005 NRSA02J-102X MG RESISTOR 1kΩ,1/10W
R7006 NRSA02J-113X MG RESISTOR 11kΩ,1/10W
R7007 NRSA02J-330X MG RESISTOR 33Ω,1/10W
R7008 NRSA02J-394X MG RESISTOR 390kΩ,1/10W
R7009 NRSA02J-103X MG RESISTOR 10kΩ,1/10W
R7010 NRVA02D-104X CMF RESISTOR 100kΩ,1/10W
R7011 NRSA02J-223X MG RESISTOR 22kΩ,1/10W
R7012 NRSA02J-221X MG RESISTOR 220Ω,1/10W
R7013 NRSA02J-102X MG RESISTOR 1kΩ,1/10W
R7014 NRSA02J-472X MG RESISTOR 4.7kΩ,1/10W
R7015 NRSA02J-223X MG RESISTOR 22kΩ,1/10W
R7016 NRSA02J-122X MG RESISTOR 1.2kΩ,1/10W
R7017 NRSA02J-472X MG RESISTOR 4.7kΩ,1/10W
R7018 NRSA02J-223X MG RESISTOR 22kΩ,1/10W
R7019 NRSA02J-120X MG RESISTOR 12Ω,1/10W
R7020 NRS181J-685X MG RESISTOR 6.8MΩ,1/8W
R7021 NRSA02J-475X MG RESISTOR 4.7MΩ,1/10W
R7022 NRSA02J-475X MG RESISTOR 4.7MΩ,1/10W
R7023 NRSA02J-564X MG RESISTOR 560kΩ,1/10W
R7024 NRSA02J-105X MG RESISTOR 1MΩ,1/10W
R7025 NRSA02J-275X MG RESISTOR 2.7MΩ,1/10W
R7026 NRSA02J-275X MG RESISTOR 2.7MΩ,1/10W
R7029 NRSA02J-102X MG RESISTOR 1kΩ,1/10W
R7030 NRSA02J-102X MG RESISTOR 1kΩ,1/10W
VR7001 NVP0001-221X TRIM RESISTOR,V.SIZE
VR7002 NVP0001-225X TRIM RESISTOR,BRIGHT
VR7003 PERE0595-565 V RESISTOR,FOCUS
C7001 QFV21HJ-104AZ F CAPACITOR 0.1µF,50V
C7002 QEDP1AM-227 E CAPACITOR 220µF,10V
C7003 QEDP1AM-227 E CAPACITOR 220µF,10V
C7004 QEDP1AM-227 E CAPACITOR 220µF,10V
C7005 NCF21CZ-105X CAPACITOR 1µF,16V
C7006 NCB21HK-152X CAPACITOR 0.0015µF,50V
C7007 NCB11CK-105X CAPACITOR 1µF,16V
C7008 NCF21CZ-105X CAPACITOR 1µF,16V
C7009 PECA1131-A107 E CAPACITOR 100µF,10V
C7010 PECA1135-Y CAPACITOR 5600pF,100V
C7011 NDC21HJ-180X CAPACITOR 18pF,50V
C7012 QEKC1HM-105 E CAPACITOR 1µF,50V
C7013 NCF21HZ-104X CAPACITOR 0.1µF,50V
C7014 NCF21HZ-104X CAPACITOR 0.1µF,50V
C7015 QCZ0136-151Z CAPACITOR 150pF,1kV
C7016 PECA1133 CAPACITOR 300pF,500V
L7001 QQR0970-001 LINEARITY COIL
L7002 PU49993-101 COIL 100µH
L7003 PELN1101-680JY COIL 68µH
T7001 QQH0011-002 FB TRANSF
CN7001 PEMC0856-4 CONNECTOR
CN7002 WJL0002-001A E-SI C WIRE B-B
CN7003 WJK0025-001A E-SI C WIRE C-B
5-19
9901 (Ozaki)-M12A6/A6C
GR-AX640U/UC/AX840U/UC
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
5.5 ELECTRICAL PARTS LIST
