JVC GR-AX655

21
SEL
F1
F2
FOCUS EXP.
F1
F2
F1
+
F1
+
Manual Focus
NOTE:
You should already have made the necessary viewfinder
adjustments ( Z pg. 11). If you haven’t, do so before
continuing.
SELECT MODE
1
Press Function SEL. repeatedly until “FOCUS”
appears to the right of F1.
ADJUST FOCUS
2
A
TO FARTHER SUBJECT
2
While holding down F1, slide the power zoom
switch to T. The Manual Focus indications “ ”
appear and “ ” blinks.
Go to step 3.
B
TO NEARER SUBJECT
While holding down F1, slide the power zoom
switch to W. The Manual Focus indications
“
” appear and “ ” blinks.
Go to step 3.
LOCK FOCUS
3
Release the power zoom switch. The focus
indication is replaced by the focus lock indication
“ ” and the adjusted focus is locked in.
RELEASE MANUAL FOCUS MODE
4
Press F1. The Manual Focus mode is immediately
released and the focus lock indication disappears.
NOTES:
● Be sure to focus the lens in the maximum telephoto
position when you use the Manual Focus mode. If you
focus in on a certain subject in the wide-angle position,
sharply focused images cannot be obtained when
zoomed up because the depth-of-field is reduced at
longer focal lengths.
● Two manual focusing speeds are available. For
slow-speed, push the switch slightly and hold that
position. For fast-speed, push the switch fully.
● When the focus level cannot be adjusted any farther or
closer, “ ” or “ ” will blink.
F1 button F2 button
Function SEL.
button
Power zoom switch
Viewfinder
