EN 47
Controls
1 Power Zoom Button ........................... Z pg. 18
2 Select Dial ......................................... Z pg. 22
3 Multi-Function Control
•EFFECT Button ................................. Z pg. 24
•WIDE Button ...................................
Z pg. 25
•TITLE Button ....................................
Z pg. 26
•SUPER LOLUX Button .....................
Z pg. 25
4 PUSH Button ...................................... Z pg. 13
5 Recording Mode [SP/EP] Button ......... Z pg. 12
6 DATE/TIME Button ............................. Z pg. 21
COUNTER R/M Button .......................
Z pg. 40
7 P. [Picture] STABILIZER Button ........... Z pg. 19
8 REW Button ....................................... Z pg. 38
RETAKE R [Quick Review] Button ......
Z pg. 19
9 PLAY/PAUSE Button ........................... Z pg. 38
0 FF Button ........................................... Z pg. 38
RETAKE F Button ................................
Z pg. 19
! STOP Button ...................................... Z pg. 38
@ EJECT Switch ...................................... Z pg. 13
# Function Navigator Dial
[MENU Jog Dial] ................................ Z pg. 11
$ LIGHT OFF/AUTO/ON Switch ........... Z pg. 20
% BATT. [Battery] RELEASE Switch ......... Z pg. 8
^ Diopter Adjustment ............................ Z pg. 14
& Recording Start/Stop Button ................ Z pg. 16
* Power Switch ................................ Z pg.16, 38
( LENS COVER Switch .......................... Z pg. 16
Connectors
) DC IN Jack ......................................... Z pg. 9
The jacks q to r are located beneath the jack
cover.
q J terminal [JLIP (Joint Level Interface Protocol)
Connector.]
• It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
• JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with
a J terminal.
w VIDEO OUT Connector ..................... Z pg. 37
e RF DC OUT Connector ...................... Z pg. 37
r AUDIO OUT Connector .................... Z pg. 37
Indicators
t Power Indicator .................................. Z pg. 16
y Tally Lamp ......................................... Z pg. 16
Other Parts
u Video Light ......................................... Z pg. 20
i Microphone
o •Camera sensor
Be careful not to cover this area; built-in
here is the sensor necessary for shooting.
p Clock Battery Compartment ............... Z pg. 10
Q Battery Pack Mount ............................ Z pg. 8
W Shoulder Strap Eyelets ........................ Z pg. 15
E Electronic Viewfinder ......................... Z pg. 14
R Grip Strap .......................................... Z pg. 14
T Tripod Mounting Socket ..................... Z pg. 15
