JVC GR-AX841U

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽
MECHANISM ASSEMBLY <M3>
401 LY20182-001B MAIN DECK ASSY
402 YQ32218 C.GUIDE(L)
403 YQ44457 SCREW
404 YQ31856A-3 MOTOR BRACKET ASSY
405 YQ20793 WORM BRACKET
406 YQ44457 SCREW,X3
407 YQ31783 WHEEL GEAR
408 YQ44328 MIDDLE GEAR
409 YQ43849B CANCEL LEVER ASSY
410 PQM30017-27 SLIT WASHER,X2
411 YQ20827-2-1 CONTROL CAM
412 LY30015-001A SLIT WASHER
413 YQ43853A LOADING GEAR(T)ASSY
414 PQM30017-27 SLIT WASHER
415 YQ43852A LOADING GEAR(S)ASSY
416 PQM30017-27 SLIT WASHER
417 YQ43634 COVER PLATE
418 YQ43635C-12 LOADING RING ASSY
419 YQ44457 SCREW,X4
420 YQ10516-1-11 GUIDE RAIL
421 YQ44457-5 SCREW,X8
422 YQ43646A-4 SUPPLY POLE BASE ASSY
423 YQ43654A-11 TAKE-UP POLE BASE ASSY
424 YQ44439A-2 DRIVE LEVER ASSY
425 YQ43663C-7 SLANT ARM ASSY
425A YQ43670 TOR.SPRING(S)
426 PQM30017-27 SLIT WASHER
427 YQ44436A-3 ROLLER BASE ASSY
428 YQ44457 SCREW
429 YQ32230 LINK LEVER
430 YQ43682B LINK ARM ASSY
431 PQM30017-25 SLIT WASHER
432 LY40018-001A PINCH ROLLER ARM ASSY
433 PQM30017-25 SLIT WASHER
434 YQ44591B TAKE-UP GUIDE ARM ASSY
435 PQM30017-27 SLIT WASHER
436 YQ44199C-7 TENSION ARM ASSY
436A YQ43848-1-2 TENSION SPRING
437 PQM30017-27 SLIT WASHER
438 YQ20797-1-3 MOTOR BASE
439 YQ44457 SCREW,X2
440 YQ44460 SCREW
441 YU42078-2 CAPSTAN MOTOR
442 YQ44304 TAPPING SCREW,X3
443 YQ43708A-3 SLANT POLE BASE ASSY
444 YQ44304 TAPPING SCREW
445 YQ43710 TIMING BELT
446 YQ43711B-10 CENTER PULLEY UNIT
447 YQ44457-2 SCREW,X2
448 YQ43729A-2 SUPPLY CLUCH ASSY
449 PQM30017-27 SLIT WASHER
450 YQ31861-1-7 REEL DISC
451 Q03093-835 WASHER
452 YQ31787 TAKE-UP GEAR
453 YQ43737 BRAKE SUB GEAR
454 PQM30017-27 SLIT WASHER,X3
455 YQ43738D A/C HEAD UNIT
456 SPSN1750Z SCREW,X2
457 YQ43743B EJECT LEVER ASSY
458 PQM30017-27 SLIT WASHER
459 YQ31833-1-1 LED GUIDE
460 YQ44457 SCREW
461 YQ43818 DRUM SPACER
462 YQ44457 SCREW,X2
465 YMA0027A MECHA(A) ASSY
466 YU42051 BRUSH
467 YQ44457-3 SCREW
468 YDV2090A DRUM ASSY
468A YDM1003-1-5 CATCHER
468B QYSPSPU1735M SCREW,X2
469 YQ44457 SCREW,X2
470 SPSH1740Z SCREW
475 YQ32219 SW.LEVER(L)
476 YQ44422-1-1 TORSION SPRING
478 QSW0745-001 ROTARY ENCODER
479 YQ44457-2 SCREW,X4
480 LY40320-002A SPECIAL SCREW
