Controls
1 MONITOR OPEN Switch.................... Z pg. 16
2 REW Button ....................................... Z pg. 34
RETAKE R [Quick Review] Button .......
Z pg. 19
3 FF Button ........................................... Z pg. 34
RETAKE F Button ................................
Z pg. 19
4 PLAY/PAUSE Button ........................... Z pg. 34
5 STOP Button ...................................... Z pg. 34
6 SEL. Button ........................................ Z pg. 25
7 SET Button ......................................... Z pg. 25
8 Power Zoom Lever ............................ Z pg. 18
9 DISPLAY Button ................................. Z pg. 15
0 MENU Button .................................... Z pg. 30
! Multi-Function Control
•Exposure +/– ...................................
Z pg. 24
•Focus FAR/NEAR ............................. Z pg. 22
•Menu Setting Change .......................
Z pg. 30
•Tracking +/– ....................................
Z pg. 35
@ PUSH Button ..................................... Z pg. 13
# EJECT Switch ...................................... Z pg. 13
$ BATT. [Battery] RELEASE Switch ......... Z pg. 8
% Diopter Adjustment............................ Z pg. 10
^ Recording Start/Stop Button ................ Z pg. 15
& POWER Switch .............................. Z pg.15, 34
* Recording Mode [SP/EP] Select
Button ................................................ Z pg. 12
R.A.EDIT CANCEL Button ...................
Z pg. 40
( R.A.EDIT IN/OUT Button .................... Z pg. 40
) Tape Length [T20•30•40]
Select Button...................................... Z pg. 12
COUNTER R [Reset]/M [Memory]
Button ................................................
Z pg. 35
q EDIT Button ....................................... Z pg. 41
w R.A.EDIT Button................................. Z pg. 40
e PICTURE STABILIZER Button .............. Z pg. 24
r PROGRAM AE Select Dial .................. Z pg. 20
t BRIGHT Dial ..................................... Z pg. 34
y VOLUME Dial ................................... Z pg. 34
Connectors
u J terminal (JLIP (Joint Level Interface Protocol)
Connector.)
(Located beneath the jack cover)
• Connect the Editing Cable when performing
Random Assemble Editing (
Z pg. 40).
•It is used to connect the camcorder to a device
such as a personal computer.
For further detail consult your nearest JVC
dealer.
i DC IN Jack ......................................... Z pg. 9
The jacks
o to Q are located beneath the jack
cover.
o VIDEO OUT Jack ............................... Z pg. 36
p RF DC OUT Jack ................................ Z pg. 36
Q AUDIO OUT Jack .............................. Z pg. 36
Indicators
W Tally Lamp ......................................... Z pg. 15
E Power On Indicator ........................... Z pg. 15
Other Parts
R Camera sensor
Be careful not to cover this area; built-in
here is the sensor necessary for shooting.
T Microphone
Y Shoulder Strap Eyelets ........................ Z pg. 14
U Clock Battery Compartment ................ Z pg. 10
I Battery Pack Mount ........................... Z pg. 8
O Electronic Viewfinder......................... Z pg. 10
P LENS COVER Switch ......................... Z pg. 15
a Grip Strap .......................................... Z pg. 14
s Speaker .............................................. Z pg. 34
d Tripod Mounting Socket ......................Z pg. 14
To Next Page
