GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
1
Rewind Button [1
] (
pg. 21)
Left Button [
1
]
Quick Review Button [QUICK REVIEW]
(
pg. 21)
2
Set Button [SET] (
pg. 16)
Data Battery Button [DATA] (
pg. 14)
3
Stop Button [7
] (
pg. 21)
Down Button [
4
]
Backlight Compensation
Button [BACKLIGHT]
4
VIDEO/MEMORY Switch (
pg. 15)
5
Play/Pause Button [6
] (
pg. 21)
Up Button [
3
]
Manual Focus Button [FOCUS] (
pg. 34)
6
Wide (16:9) Button [16.9] (
pg. 33)
Blank Search [BLANK] ( pg. 22)
7Menu Button [MENU] ( pg. 29)
8Fast-Forward Button [¡] ( pg. 21)
Right Button [2]
Night Button [NIGHT] ( pg. 33)
9Index Button [INDEX] ( pg. 25)
LED Light Button [LIGHT]
!Diopter Adjustment Control ( pg. 17)
"Auto Button [AUTO] ( pg. 15)
#Snapshot Button [SNAPSHOT]
( pg. 24, 34)
Live Slow Button ( pg. 29, 33)
$Power Zoom Lever [T/W] ( pg. 20)
Speaker Volume Control [VOL. +, –]
( pg. 21)
%Battery Release Button [PUSH BATT.]
( pg. 13)
&Recording Start/Stop Button ( pg. 19)
(Power Switch [REC, PLAY, OFF] ( pg. 15)
)Lock Button ( pg. 15)
~Cassette Open/Eject Switch [OPEN/EJECT]
( pg. 18)
Connectors
The connectors are located beneath the covers.
+USB (Universal Serial Bus) Connector
( pg. 41)
,Digital Video Connector [DV IN/OUT] (i.LINK*)
( pg. 40, 41)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.LINK
standard.
-Audio/Video Output Connector [AV]
( pg. 23, 39)
.DC Input Connector [DC] ( pg. 13)
Indicators
ç
POWER/CHARGE Lamp ( pg. 13, 19)
Other Parts
é
LCD Monitor ( pg. 19, 20)
è
Viewfinder ( pg. 17)
ê
Card Cover [ ] ( pg. 18)
ë
Battery Pack Mount ( pg. 13)
í
Shoulder Strap Eyelet ( pg. 12)
ì
Grip Strap ( pg. 16)
î
Speaker ( pg. 21)
ï
Lens
ñ
LED Light
ó
Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
ò
Stereo Microphone
ô
Stud Hole ( pg. 17)
ö
Tripod Mounting Socket ( pg. 17)
õ
Cassette Holder Cover ( pg. 18)
ú
Memory Card Slot
