JVC GR-D750UC - Page 15

(No.YF173)1-15
Fig.3-2-3
0.069 N࡮m (0.7kgf࡮cm)
0.078 N࡮m (0.8kgf࡮cm)
[18]
NOTE18a
b
bb
a
MONITOR BOARD
ASSY
HINGE ASSY
M.COVER ASSY
SHEET(M.REF)
LIGHT GUIDE
SHEET(M.DIFF)
SHEET(BEF)
S.CASE(MONI)
LCD MODULE
LCD CASE
MONITOR CASE
H.COVER(U)
HINGE ASSY
H.COVER(L)
P.C.MAGNET
1
(S18a)
2
(S18a)
3
(S18b)
4
(S18c)
CN18a
CN18b
aa
NOTE18e,f
FPC
MONITOR CASE SIDE
SUPPORT PLATE
SIDE
M.COVER ASSY SIDE
NOTE18b
LCD CASE
LCD MODULE
S.CASE(MONI)
NOTE18c
L18h
L18k
L18j
L18aL18bL18e
L18f
L18g
L18d
L18c
P.C.MAGNET
H.COVER(L)
N pole
S pole
<NOTE18d>
<NOTE18c>
KNOB(CURSOL)
