JVC GR-DVF10 Technical Guide

2-17
•
••
•
Camera DSP (IC4301: JCY0120) pin functions (2/6)
Pin No. Label In/Out Description
65 DSYI3
276 DSYI4
214 DSYI5
144 DSYI6
213 DSYI7
217 DSCI0
148 DSCI1
68 DSCI2
278 DSCI3
216 DSCI4
67 DSCI5
147 DSCI6
66 DSCI7
30 TVSEL In TV system select (L: NTSC, H: PAL)
112 CPUSEL0 In CPU select (L: n, H: M)
185 CPUSEL1 In CPU select 1 (L: MN2_H: MN3)
273 VDDI - Power supply for Digital (I/O, internal)
275 ADDVDDE - Power supply for add Digital (I/O)
106 TCK
178 TMS
245 TRST In Test terminal (for JTAG with pull-up)
179 TDIN
105 TDOUT
31 ADDVSS - Ground for add Digital
252 VDDI - Power supply for Digital (I/O, internal)
21 ADDVSS - Ground for add Digital
22 VSS - Ground for Digital
125 DACTEST In Test terminal for DAC
184 AVDDA - Power supply for Analog sound
250 DVDDM - Power supply for DAC
248 AVDDV2 - Power supply Analog video
249 AVSSA - Ground for Analog sound
26 AVSSV2 - Ground for Analog video
28 VREFHK In Reference voltage input, top side (for shutter sound)
111 VREFLK In Reference voltage input, bottom side (for shutter sound)
29 K_OUT Out Shutter sound output
25 IREFVF In/Out Reference register terminal for current adjustment, (for VF signal)
110 VREFVF In Reference voltage input terminal for adjustment, (for VF signal)
27 B-Y_OUT Out B
−
Y signal output for VF
182 R-Y_OUT Out R
−
Y signal output for VF
24 IREFC In/Out Reference register terminal for current adjustment,(for chromatic signal)
247 VREFC In Reference voltage input terminal for adjustment,(for chromatic signal)
109 C_OUT Out Modulation color signal output
23 IREFY In/Out Reference register terminal for current adjustment,(for luminance signal)
107 VREFY In Reference voltage input terminal for adjustment,(for luminance signal)
181 Y_OUT Out Luminance signal output
183 Y2_OUT Out Luminance signal output for VF
108 AVSSV1 - Ground for Analog video
Not used-
In Digital luminance signal input for DSC
In Digital color difference signal input for DSC
Not used-
Not used-
Table 2-4-1 Camera DSP (IC4301: JCY0120) pin functions (2/6)
