JVC GR-DVF10 Technical Guide

2-18
•
••
•
Camera DSP (IC4301: JCY0120) pin functions (3/6)
Pin No. Label In/Out Description
246 AVDDV1 - Power supply for Analog video
180 NC - Not used
222 AVSSE3 - Ground for EVR
79 VREFL3 In Reference voltage input for bottom side
75 VREFH3 - Power supply for EVR
78 AVDDE3 - Power supply for EVR
223 DVDDM - Power supply for DAC
220 AVSSE2 - Ground for EVR
221 VREFL2 In Reference voltage input for bottom side
74 VREFH2 In Reference voltage input for top side
75 AVDDE2 - Power supply for EVR
279 NC - Not used
71 AVSSE1 - Ground for EVR
150 VREFL1 In Reference voltage input for bottom side
218 VREFH1 In Reference voltage input for top side
72 AVDDE1 - Power supply for EVR
149 EOUT1 Out EVR output 1
280 EOUT2 Out EVR output 2
219 EOUT3 Out EVR output 3
73 EOUT4 Out EVR output 4
281 EOUT5 Out EVR output 5
151 EOUT6 Out EVR output 6
152 EOUT7 Out EVR output 7
282 EOUT8 Out EVR output 8
77 EOUT9 Out EVR output 9
153 EOUT10 Out EVR output 10
283 EOUT11 Out EVR output 11
154 EOUT12 Out EVR output 12
162 ADDVDDE - Power supply for add Digital (I/O)
126 ADDVSS - Ground for add Digital
167 ADDVDDE - Power supply for add Digital (I/O)
284 VSS - Ground for Digital
286 VDDE - Power supply for Digital (I/O)
269 VSS - Ground for Digital
266 VDDE - Power supply for Digital (I/O)
254 VSS - Ground for Digital
263 ADDVDDE - Power supply for add Digital (I/O)
192 ADDVSS - Ground for add Digital
177 ADDVDDE - Power supply for add Digital (I/O)
101 NAND2_O Out NAND 2 output
102 NAND2_B In NAND 2 input B
176 NAND2_A In NAND 2 input A
175 NAND1_O Out NAND 1 output
242 NAND1_B In NAND 1 input B
103 NAND1_A In NAND 1 input A
15 ADDVDDE - Power supply for add Digital (I/O)
274 VSS - Ground for Digital
267 VDDI - Power supply for Digital (I/O, internal)
Table 2-4-1 Camera DSP (IC4301: JCY0120) pin functions (3/6)
