REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
PW MONITOR BOARD ASSY YB10360PB-02 YB10360PG-02 YB10360PD-02
D11 SI DIODE — RSA6.1J4-W
R7 MG RESISTOR — NRSA63J-103X
R8 MG RESISTOR — NRSA63J-152X
R9 MG RESISTOR — NRSA63J-182X
R10 MG RESISTOR — NRSA63J-272X
R18 MG RESISTOR — NRSA63J-473X
R19 MG RESISTOR — NRSA63J-103X
R21 MG RESISTOR — NRSA63J-103X
R22 MG RESISTOR — NRSA63J-473X
R23 MG RESISTOR — NRSA63J-104X
R7612 CMF RESISTOR NRVA63D-223X NRVA63D-682X
R7624 CMF RESISTOR —— ——— —NRVA63D-223X
R7625 CMF RESISTOR —— ——— —NRVA63D-223X
C11 T CAPACITOR — NBE20JM-106X
C7636 CAPACITOR —— ——— —NCF31CZ-104X
L10 FERRITE BEAD — NQR0129-002X
L7605 COIL NQL365K-100X —
L7606 COIL —— ——— —NQL365K-100X
SW6 SLIDE SWITCH — NSW0099-001X
SW7 TACT SWITCH — NSW0160-001X
SW8 TACT SWITCH — NSW0160-001X
SW9 TACT SWITCH — NSW0160-001X
SW10 TACT SWITCH — NSW0160-001X
CN762 FPC CONNECTOR — QGF0508F1-10
CN766 SD CARD CONNECTOR — NNZ0058-001X
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
PW MAIN BOARD ASSY YB10359PA-03 YB10359QD-03 YB10359PB-03
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
500 MONITOR ASSY LYH20246-036A LYH20246-040A LYH20246-037B
501 MONITOR COVER ASSY LY20808-001A LY20808-002A LY20809-002A
502 MONITOR CASE LY10264-001A LY20598-002A
502A EARTH MON(2) —— ——— —LY42388-001A
504 HOLDER LY20674-001A LY20568-001A
506 BACK LIGHT QLL0093-001 QLL0115-001
507 LCD MODULE QLD0154-001 QLD0203-001
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
321 CASE B(VF) LY20767-001A * LY20767-001B
323 LEVER(VF) LY43231-001A * LY43231-001B
324 LENS ASSY LY32472-001A * LY32472-002A
2
FINAL ASSEMBLY <M2>
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
101 UPPER CASE ASSY LY20774-001B LY20774-005B LY20797-004B
101A TOP COVER LY20775-001A LY20776-001A
101B PLATE(UPPER) LY32371-002A LY32371-003A
101E COVER(SD) — LY32375-001A
101F SHAFT — LY43292-001A
101G SPRING — LY43293-001A
101J EARTH SHEET LY43540-001A LY43541-001A
101M SPECIAL SCREW,X2 LY30018-084A LY30018-038A
101N COVER(SD)DUMMY LY32376-001A ——————
101P SPECIAL SCREW LY30018-023A ——————
108 KNOB(SLIDE) — LY43263-002A
113 FFC WIRE — QUQ105-1011AA
119 WINDOW LY32378-009A LY32379-005A
120 STICKER(SIDE) LY43566-002A LY43566-005A LY43566-003A
126 STICKER(TOP) LY43567-001A LY43567-003A
140 LOWER CASE ASSY LY20769-002B LY20769-004C
164 SPECIAL SCREW — LY30019-038A
ELECTRONIC VIEWFINDER ASSEMBLY <M4>
MONITOR ASSEMBLY <M5>
MAIN BOARD ASSEMBLY <01>
MONITOR BOARD ASSEMBLY <02>
Notes : Mark is same as left.
Mark — is not used.
Mark * reference model was also changed.
