3
CCD BOARD ASSEMBLY <04>
JACK BOARD ASSEMBLY <06>
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
PW JACK BOARD ASSY YB10357A-01 YB10357B-01
R515 MG RESISTOR/FERRITE BEAD NRSA63J-0R0X NQR0022-005X
R520 MG RESISTOR — NRSA63J-0R0X
R521 MG RESISTOR — NRSA63J-0R0X
L504 FERRITE BEAD — NQR0251-004X
L505 FERRITE BEAD — NQR0251-004X
L506 FERRITE BEAD — NQR0251-004X
J502 3.5 JACK — QNS0005-001
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
PW CCD BOARD ASSY YB20914A-01 YB20914E
Q5202 TRANSISTOR — 2SC4081/RS/-X
R5202 MG RESISTOR NRSA63J-0R0X ——————
R5205 MG RESISTOR — NRSA63J-472X
WR1 E-SI C WIRE C-F WJM0290-001A WJM0296-001A
REAR BOARD ASSEMBLY <07>
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
PW REAR BOARD ASSY YB10362A-01 YB10362B-01
D551 ZENER DIODE EMZ6.8N ——————
D552 ZENER DIODE EMZ6.8N ——————
R555 MG RESISTOR NRSA63J-331X ——————
R556 MG RESISTOR NRSA63J-331X ——————
R557 MG RESISTOR — NRSA63J-0R0X
R558 MG RESISTOR — NRSA63J-0R0X
R559 MG RESISTOR — NRSA63J-0R0X
J552 2.5 JACK QNS0152-001 ——————
J553 USB CONNECTOR — QNZ0497-001
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
PW DSC BOARD ASSY — YB20915C-03
DSC BOARD ASSEMBLY <10>
Notes : Mark is same as left.
Mark — is not used.
