JVC GR-DVM75 - Page 99

For Connectors
’ AV
Video output : 1 V (p-p), 75 Q, analog
Video input (CR-DVM75 only)
: 0.8 V (p-p) - 1.2 V (p-p), 75 R, analog
Audio output
: 300 mV (rms), 1 kR, analog, stereo
Audio input (CR-DVM75 only)
: 300 mV (rms), 50 kQ, analog, stereo
Headphone output (CR-DVM75 only): Stereo
DV
Input/output
: 4.pin, IEEE 1394 compliant
Power requirement
U.S.A. and Canada
Other countries
output
Dimensions (W x H x D)
Weight
: ACl20V~,60Hz
: AC 110 V to 240 VQ.,, 50 Hz/60 Hz
: DCIIVZZ,IA
: 59 mm x 31 mm x 84 mm (2.3/8” x 1 -l/4” x 3-5/16”)
: Approx. 130 g (0.29 Ibs)
For General
Dimensions (W x H x D)
Weight
For Connectors
: 52 mm x 22 mm x 73 mm (2-l/1 6” x 7/8” x 2-7/8”)
: Approx. 35 g (0.78 Ibs)
USB (CR-DVM75 only)
EDIT (CR-DVM75 only)
S-Video
output
: Type B
: 03.5 mm, 2-pole
Input (CR-DVM75 only)
JLIP (CR-DVM55 only)
PC (DIGITAL PHOTO)
(CR-DVM55 only)
: Y : 1 V (p-p), 75 R, analog
C : 0.29 V (p-p), 75 Q, analog
: Y : 0.8 V (p-p) - 1.2 V (p-p), 75 R, analog
c : 0.2 V (p-p) - 0.4 V (p-p), 75 a, analog
: 03.5 mm, 4-pole
: 02.5 mm, 3-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
.
