# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

5.2 ELECTRICAL PARTS LIST (GR-DVX78A/A-S/EA)

******************************

MAIN BOARD ASSEMBLY <01>

PW YB10319C-02 MAIN BOARD ASSY

IC1001 UPD703039F1-A10 IC(MICRO C ROM)

or UPD70F3040F1A10 IC

IC1002 RS5C314 IC

IC1003 AT25160N-10SC-X IC

or NM25C160LZEM8 IC

or X25170S8I-2.5-X IC

IC1004 TC75S56FU IC

IC1005 TC7S00FU IC

or SN74AHC1G00K IC

IC1006 MB90097PFV142 IC(MICRO C ROM)

IC1007 TC74VHC08FT IC(DIGITAL)

or SN74LV08APW IC

IC1009 IC-PST9323U-X IC

IC1101 TA75W01FU IC

IC1303 SN74LV02APW IC

IC1401 YQ44888A CSP IC ASSY

IC1404 TC7W14FU IC(DIGITAL)

or SN74AHC2G14T IC

IC3001 JCY0133 IC

IC3002 JCY0136 IC

IC3003 TLC2940IPW IC

IC3004 SN74AHC1G04K IC

IC3006 JCY0164 IC

IC3501 JCY0132 IC

IC3701 MM1510XN IC

IC3702 MM1510XN IC

IC3703 MM1506XN IC

IC3901 JCP8029 IC

IC3951 MM1504XN IC

IC4201 HD49326BF IC

IC4202 MM1385HN IC

IC4301 JCY0150 IC

IC4302 TMS4C2973-28-X IC

IC4303 TMS4C2973-28-X IC

IC5501 JCY0117 IC

IC6001 S-80842ANNP-W IC

IC6002 S-817A33ANB-W IC

IC6101 FA3698F IC

IC6601 TC7W74FU IC(DIGITAL)

or TC7WH74FU IC(DIGITAL)

IC8001 JCY0121-4 IC

IC8002 MSM56V16160D1LS IC

IC8003 M32310D5WG IC

IC8004 39VF800A7CEKA10 IC(MICRO C ROM)

or 39VF800A9CEKA10 IC(MICRO C ROM)

or LE28DW8163T8A03 IC(MICRO C ROM)

IC8005 SN74AHC1G00K IC

or TC7S00FU IC

IC8006 MM1385NN IC

IC8007 MM1385EN IC

IC8008 TC7WHU04FU IC

IC8009 TC7WH74FK IC

IC8010 TC7SH08FU IC(DIGITAL)

IC8011 TC7WH74FK IC

IC8012 TC7WH32FK IC

IC8101 TMS320DA050-G IC

or TMS320DA050 IC

IC8102 TC7MA2244FK IC

IC8103 TC7S04FU IC(DIGITAL)

IC8401 ML60851CLB IC

or ML60851DLB IC

IC8402 S-80842ANNP-W IC

Q1001 DTC124EE TRANSISTOR

or UN9212J TRANSISTOR

Q1002 2SC4617/QR/-X TRANSISTOR

Q1003 DTC143EE TRANSISTOR

or RN1101 TRANSISTOR

or UN921LJ TRANSISTOR

Q1004 DTA114EE TRANSISTOR

or PDTA114EE TRANSISTOR

or RN2102 TRANSISTOR

or UN9111J TRANSISTOR

Q1005 DTC144EE TRANSISTOR

or UN9213J TRANSISTOR

or PDTC144EE TRANSISTOR

or RN1104 TRANSISTOR

Q1006 DTA114EE TRANSISTOR

or PDTA114EE TRANSISTOR

or RN2102 TRANSISTOR

or UN9111J TRANSISTOR

Q1007 DTC144EE TRANSISTOR

or UN9213J TRANSISTOR

or PDTC144EE TRANSISTOR

or RN1104 TRANSISTOR

Q1301 2SC4617/RS/-X TRANSISTOR

Q1401 DTA114EE TRANSISTOR

or PDTA114EE TRANSISTOR

or RN2102 TRANSISTOR

or UN9111J TRANSISTOR

Q1402 UMC3N TRANSISTOR

Q1403 UMC3N TRANSISTOR

Q1404 DTC144EE TRANSISTOR

or PDTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR

Q3701 UMT2N PAIR TRANSISTOR

Q3702 2SA1774/RS/-X TRANSISTOR

Q3703 UMZ1N PAIR TRANSISTOR

or PUMZ1 PAIR TRANSISTOR

Q3704 2SC4617/RS/-X TRANSISTOR

Q3951 UMZ1N PAIR TRANSISTOR

or PUMZ1 PAIR TRANSISTOR

Q3952 DTC144EE TRANSISTOR

or PDTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR

Q3953 UMZ1N PAIR TRANSISTOR

or PUMZ1 PAIR TRANSISTOR

Q3954 2SC4617/RS/-X TRANSISTOR

Q4301 UMT2N PAIR TRANSISTOR

Q4302 UMT2N PAIR TRANSISTOR

Q6001 DTC144EE TRANSISTOR

or PDTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR

Q6002 2SK3019 MOS FET

Q6003 2SJ347 MOS FET
