EN5
A
B
3
1
2
3
2
1
Using the battery pack
Hook its end to the camcorder ( ) and push the
battery pack in until it locks in place ( ).
(Charging procedure, Z pg. 6)
To remove the battery pack
Slide BATTERY RELEASE and pull out the battery
pack.
QUICK OPERATION GUIDE
1 Set the Power Switch to “PLAY”.
2 Press REW (
2
).
— The tape will automatically stop at the
beginning of the tape.
3 Press PLAY/PAUSE (
4
/6).
— Playback starts and the playback picture
appears.
•To stop playback, press STOP (5).
(For more details, Z pg. 34)
Or simply play back the tape on a VHS VCR
using the Cassette Adapter
Z pg. 37
1 Turn the LENS COVER Open/Close Ring to
open the lens cover.
2 Set the Power Switch to “AUTO” or “PRO.”.
— The power lamp will light and an image
will appear.
3 Press the Recording Start/Stop Button.
— Recording starts.
•To stop recording temporarily, momentarily
press the Recording Start/Stop Button once
again.
(For more details, Z pgs. 14, 15)
SUPPLY POWER
INSERTING A VIDEO CASSETTE
PLAYBACK SHOOTING
1 Slide EJECT to open the cassette holder.
2 Insert a video cassette.
3 Press PUSH to close the cassette holder.
(For more details, Z pg. 11)
Set to “PLAY”
PUSH Button
EJECT Switch
Hook on.
Push in.
BATTERY RELEASE
LENS COVER
Open/Close Ring
Set to “AUTO”
or “PRO.”
Recording Start/Stop Button
REW (
2
) Button
PLAY/PAUSE
(
4
/6) Button
STOP
(5) Button
