EN53
Controls
1 Dioptre Adjustment Control ................. Z pg. 12
2 Lens Cover Open/Close Ring................ Z pg. 14
3 5-Second Recording Button
[5 SEC REC] ......................................... Z pg. 18
4 Power Zoom Lever [T/W] ..................... Z pg. 16
5 Picture Stabilizer Button
[P. STABILIZER] .................................... Z pg. 18
6 Programme AE Button [P.AE] ................ Z pg. 20
7 Fade/Wipe Button [EFFECT] ................. Z pg. 19
8 •Rewind Button [
2
, REW] ................ Z pg. 34
•Retake Rewind Button [RETAKE R]..... Z pg. 17
•Quick Review Button [
R] ............. Z pg. 17
9 •Fast-Forward Button [
3
, FF] ............ Z pg. 34
•Retake Forward Button [RETAKE F] .... Z pg. 17
0 Stop Button [5, STOP] ......................... Z pg. 34
! Play/Pause Button
[
4
/6, PLAY/PAUSE] ............................. Z pg. 34
@ Select Dial [+, –, PUSH] .................. Z pg. 9, 24
# MENU/DISPLAY Button ................. Z pg. 15, 24
$ •Counter Reset/Memory Button
[COUNTER R/M] .............................. Z pg. 36
•Recording Mode Button [SP/LP] ......... Z pg. 10
% EJECT Switch ....................................... Z pg. 11
^ Recording Start/Stop Button.................. Z pg. 14
& Power Switch ................................ Z pg. 14, 34
* Battery Release Switch
[BATTERY RELEASE] .............................. Z pg. 6
( PUSH Button ....................................... Z pg. 11
Connectors
) DC IN Jack ............................................ Z pg. 7
The connectors q to e are located beneath the
cover.
q Video Output Connector ...................... Z pg. 38
w Audio Output Connector ..................... Z pg. 38
e J Terminal
[JLIP (Joint Level Interface Protocol) Connector]
• Connect the editing cable when performing
Random Assemble Editing (
Z pg. 42– 45).
• It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
• JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
r Tally Lamp ........................................... Z pg. 14
t Power Lamp ........................................ Z pg. 14
Other Parts
y Battery Pack Mount ............................... Z pg. 6
u Viewfinder ........................................... Z pg. 12
i Grip Strap ............................................ Z pg. 12
o • Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
• Remote Sensor .................................. Z pg. 41
p Microphone......................................... Z pg. 47
Q Eyepiece .............................................. Z pg. 48
W Shoulder Strap Eyelets .......................... Z pg. 13
E Clock Battery Slot .................................. Z pg. 8
R Tripod Mounting Socket ....................... Z pg. 13
