JVC HR-J588 Service Manual

MODEL
HR-J680EK HR-J580EK
ITEM
TABLE OF CONTENTS
DIFFERENT TABLE.................................................................................................................................................................................... 1 to 2
4. CHARTS AND DIAGRAMS (4-1 to 4-3)
4.1 ON SCREEN SCHEMATIC DIAGRAM [HR-J580EK/EU, J581EU] ........................................................................................................ 4-2
5. PARTS LIST (5-1 to 5-10)
5.1 FINAL ASSEMBLY <M2> ........................................................................................................................................................................ 5-1
5.2 ELECTRICAL PART LIST ....................................................................................................................................................................... 5-3
MAIN BOARD ASSEMBLY <03> ............................................................................................................................................................... 5-3
MINI FRONT BOARD ASSEMBLY <28> ................................................................................................................................................. 5-10
[HR-J580EK]
The following tables indicate main different points between models HR-J680EK and HR-J580EK.
The following tables indicate different parts number between models HR-J680EK and HR-J580EK.
PACKING AND ACCESSORY ASSEMBLY <M1>
Notes : Mark — is not used.
1
!
REF. MODEL
HR-J680EK HR-J580EK
NO. ITEM
SAT_CTL USED NOT USED
PLUG &PLAY AUTO SET.AUTO CLOK AUTO TUNE
VCR PLUS+ VIDEO PLUS+ DELUXE VIDEO PLUS
REC LINK USED NOT USED
DISPLAY WINDOW color LIGHT GRAY SMOKE GRAY
301 PACKING CASE LP30855-001A LP30897-001A
302 CUSHION ASSY LP30909-001B LP30898-001A
! 310 INST BOOK(EN) LPT0474-001A LPT0473-001A
313 LED CABLE ASSY QAL0095-005 —
!
REF. MODEL
HR-J680EK HR-J580EK
NO. ITEM
! 501 FRONT PANEL ASSY LP10333-012B LP10293-028B
501A CASSETTE DOOR LP20961-001A LP20868-031A
501C BUTTON(OPE) LP30798-001A —
501D DISPLAY WINDOW — LP20869-084B
501E ORNAMENT — LP30649-005A
! 502 TOP COVER LP10013-051A PQ11898-52-23
! 511 BOTTOM CHASSIS LP10108-001E LP21026-001B
! 512 BOTTOM COVER LP10014-002B PQ11899-3-7
534 PC SUPPORT,MINI FRONT — LP40628-001B
535 BRACKET — LP40854-001A
536 SCREW — QYTDSF3010Z
WR3 FF WIRE,MINI FRONT — QUQ112-0914CG
FINAL ASSEMBLY <M2>
MAIN BOARD ASSEMBLY <03>
!
REF. MODEL
HR-J680EK HR-J580EK
NO. ITEM
PW1 MAIN BOARD ASSY LPA10131-05C1 LPA10131-08E1
MINI FRONT BOARD ASSEMBLY <28>
!
REF. MODEL
HR-J680EK HR-J580EK
NO. ITEM
PW1 MINI FRONT BOARD ASSY — LPA20005-01A
SAT_CTL BOARD ASSEMBLY <92>
!
REF. MODEL
HR-J680EK HR-J580EK
NO. ITEM
PW4 SAT_CTL BOARD ASSY LPA10131-01A4 —
