1-2 (No.MB188)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section CA-HXGD8
Output Power SUBWOOFERS 195 W per channel, min. RMS, driven into 6 Ω at 63 Hz with no more than 10 % total harmonic
distortion.
MAIN SPEAKERS 80 W per channel, min. RMS, driven into 6 Ω at 1 kHz with no more than 10 % total harmonic
distortion.
Audio input sensitivity/imped-
ance (Measured at 1 kHz, with
tape recording signal 300 mV)
AUX:300 mV/47 kΩ
Digital output OPTICAL DIGITAL OUTPUT -21 dBm to -15 dBm (660 nm ± 30 nm)
VIDEO OUT Color system NTSC
VIDEO (composite) 1 V(p-p)/75 Ω
S-VIDEO Y (luminance):1 V(p-p)/75 Ω
C (chrominance, burst):0.286 V(p-p)/75 Ω
COMPONENT
(interlace/ progressive)
(Y):1 V(p-p)/75 Ω
(P B/PR):0.7 V(p-p)/75 Ω
Speaker
Terminals
MAIN SPEAKERS 6 Ω - 16 Ω ()
SUBWOOFERS 6 Ω - 16 Ω ()
Others AV COMPU LINK × 2 (Ø 3.5)
Tuner section FM tuning range 87.5 MHz - 108.0 MHz
AM tuning range 530 kHz - 1 710 kHz
Disc player section Playable disc DVD VIDEO/DVD AUDIO
CD/VCD/SVCD
CD-R/CD-RW (recorded in Audio CD/ Video CD/ Super Video CD/ MP3/ WMA/ JPEG format)
DVD-R/DVD-RW (recorded in video format)
Dynamic range 90 dB
Horizontal resolution 500 lines
Wow and flutter Immeasurable
Cassette deck section Frequency
response
Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15 % (WRMS)
General Power requirement AC 120 V , 60 Hz
Power consumption 265 W/ 325 VA (at operation)
30 W (on standby)
Dimensions (approx.) (W/H/D) 205 mm × 370 mm × 432 mm
(8 1/8 in. × 14 5/8 in. × 17 1/16 in.)
Mass (approx.) 11 kg (24.3 lbs)
Speaker section SP-HXGD8
Type 3-Way 4-Speaker Bass-Reflex Type
Speakers Subwoofer 20 cm (7 7/8 in.)cone × 1
Woofer 13.5 cm (5 3/8in.) cone × 2
Tweeter 5 cm (2 in.) cone × 1
Power handling capacity Subwoofer 195 W
Main speaker 80 W
Impedance Subwoofer 6 Ω
Main speaker 6 Ω
Frequency range Subwoofer 30 Hz - 970 Hz
Main speaker 75 Hz 25 000 Hz
Sound pressure level Subwoofer 83 dB/W·m
Main speaker 88 dB/W·m
Dimensions (approx.) (W/H/D) 240 mm × 457 mm × 407 mm
(9 1/2 in. × 18 in. × 16 1/16 in.)
Mass (approx.) 10 kg (22.1 lbs) each
