JVC HX-GX7

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 GV10177-001A FRONT PANEL
2 GV40313-001A FELT SPACER (x2)
3 GV40464-001A ARM SPRING (x2)
4 GV40492-001A COMP.SPRING (x2)
5 GV40483-001A BUTTON ASSY.(L)
6 GV40484-001A BUTTON ASSY.(R)
7 GV40482-001A SOUND BUTT.ASSY
8 GV20260-001A WINDOW SCREEN
9 GV30532-001A PRESET ORNAMENT
10 QYSDSF2608Z SCREW 2.6mm x 8mm
11 GV30534-001A VOLUME ORNAMENT
12 QYSDSF2608Z SCREW 2.6mm x 8mm
13 QYSDSF2608Z SCREW 2.6mm x 8mm
14 GV30571-001A SOUND MODE ORNA
15 GV30542-001A FUNCTION BUTTON
16 GV30541-001A BUTTON
17 GV40461-001A FUNCTION INDICA
18 GV40462-001A DISPLAY LENS (x2)
19 LV30225-011A SPACER (x2)
20 QYSDSF2608Z SCREW 2.6mm x 8mm(x8)
21 GV30570-001A CONTROL BUTT.A
22 QYSDSF2608Z SCREW 2.6mm x 8mm(x8)
23 GV30528-003A POWER BUTTON
24 GV40459-001A STANDBY INDICAT
25 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
26 GV30529-002A DISPLAY BUTTON
27 QYSDSF2608Z SCREW 2.6mm x 8mm(x3)
28 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
29 E65923-003 TAPPING SCREW
30 GV30588-001A CASS.HOLD.ASSY.
31 GV30572-001A CASS.EJECT SYS.
32 GV40034-001A DAMPER ASSY.
33 GV40398-001A SPRING
34 VKL7850-002 EJECT SAFTY(R)
35 VKW5258-003 TORSION SPRING
36 QYSBSF3012Z TAP SCREW 3.0mm x 12mm(x2)
37 QYSBSF3008Z SCREW 3mm x 8mm(x2)
38 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
39 GV10179-001A PLASTICS CHASS
40 QYSSSF3010Z TAP SCREW M3 x 10mm(x2)
41 GV10182-001A MAIN CHASSIS
42 QYSSSF3010Z TAP SCREW M3 x 10mm(x3)
43 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x2)
44 QYSBSF3008Z SCREW 3mm x 8mm(x4)
45 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
46 LV30225-079A SPACER
47 E310243-002 PLASTIC RIVET
48 LV30225-011A SPACER
49 QAU0346-001 TUNER
50 GV10181-001A CHASSIS BASE
51 QYSBSG3006Z TAPPING SCREW 3mm x 6mm(x2)
52 GV40313-002A FELT SPACER (x2)
53 GV30547-002A HEAT SINK
54 QYSBSGG3008Z TAP SCREW 3mm x 8mm
55 GV30545-001A SUPPORT BRAC.
56 QYSBSG3020E TAP SCREW 3mm x 20mm(x2)
57 GV40297-003A LEAF SPRING (x2)
58 QYSBSG3014E TAP SCREW 3mm x 14mm(x2)
59 QYSBSG3020E TAP SCREW 3mm x 20mm(x2)
60 QYSDSTL4008Z ASSY SCREW 4mm x 8mm(x4)
61 QYSBSGG3008Z TAP SCREW 3mm x 8mm
62 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
 63 QZW0033-001 STRAIN RELIEF
64 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x3)
65 GV10183-001A REAR PANEL
66 GV10199-002A REAR COVER
67 GV30544-001A FAN BRACKET
68 LV30225-011A SPACER (x2)
69 QYSBSG3030Z TAP SCREW M3 x 30mm(x2)
70 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
71 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
72 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
73 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
74 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
75 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
76 QYSBSF3012E SPECIAL SCREW 3mm x 12mm
77 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
78 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
79 GV10110-003A/S/ METAL COVER
80 QYSDSG3006M TAP SCREW 3mm x 6mm(x2)
81 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
82 GV20261-001A CD FITTING (1)
83 GV20261-002A CD FITTING (2)
84 GV20261-003A CD FITTING (3)
85 GV20261-004A CD FITTING (4)
86 GV20261-005A CD FITTING (5)
87 GV30531-001A PRESET KNOB
88 GV30604-001A SND.MODE KNOB
89 GV30540-001A FRONT LENS
90 GV30533-001A VOLUME KNOB
91 GV30589-001A RATING LABEL
92 LV42035-002A LASER CAUTION
93 VYSH101-009 SPACER
94 LV30225-011A SPACER
 95 QQT0423-001 POWER TRANSF T 001
 96 QMPD380-200-JN
POWER CORD
(US/CA)
2m BLACK
97 QAR0317-001 FAN
98 QUQH10-1718BJ CARD WIRE
99 QUQH12-0922BJ CARD WIRE
100 QUQH12-1016BJ CARD WIRE
101 QUQH12-1109AJ CARD WIRE FC 1
102 QUQH12-2315BJ CARD WIRE
103 QUQH12-1520BJ CARD WIRE
104 QUQH12-1811BJ CARD WIRE
 105 QMF51U1-6R3-J8 FUSE
F 001 6.3A
AC125V
 106 QMF51U1-8R0-J8 FUSE
F 101 8A
AC125V
 107 QMF51U1-8R0-J8 FUSE
F 102 8A
AC125V
 108 QMF51U1-3R15-J8 FUSE
F 103 3.15A
AC125V
109 GV40522-001A LUMIRROR SHEET
 Symbol No. Part No. Part Name Description Local
