JVC HX-GX7 Service Manual

3-12
Input board
Block No. [0][2][0][0]
 Symbol No. Part No. Part Name Description Local
IC125 BA33BC0T REGULATOR IC
IC401 LC75342M-X IC
IC442 JCV8011-X IC
IC466 NJM4565M-WE IC
IC467 NJM4565M-WE IC
IC485 NJM4565M-WE IC
IC486 NJM4565M-WE IC
IC526 NJM4565M-WE IC
IC534 CD4066BM-X IC
IC801 UPD784215AGF540 IC
IC802 BR24L01AF-W-X IC
IC951 GP1UM271XK IR DETECT UNIT 38kHz
IC956 NJM4565M-WE IC
Q100 2SD601A/RS/-X TRANSISTOR
Q101 2SD601A/RS/-X TRANSISTOR
Q110 UN2211-X TRANSISTOR
Q111 UN2213-X DIGI TRANSISTOR
Q442 KTC3199/GL/-T TRANSISTOR
Q485 2SD601A/RS/-X TRANSISTOR
Q486 2SD601A/RS/-X TRANSISTOR
Q487 2SD601A/RS/-X TRANSISTOR
Q515 2SD1328/ST/-X TRANSISTOR
Q516 2SD1328/ST/-X TRANSISTOR
Q517 2SD1328/ST/-X TRANSISTOR
Q534 UN2213-X DIGI TRANSISTOR
Q535 UN2213-X DIGI TRANSISTOR
Q540 UN2113-X TRANSISTOR
Q541 2SD1328/ST/-X TRANSISTOR
Q542 2SD1328/ST/-X TRANSISTOR
Q567 KTA1267/YG/-T TRANSISTOR
Q568 UN2211-X TRANSISTOR
Q594 2SD601A/RS/-X TRANSISTOR
Q595 UN2215-X TRANSISTOR
Q802 UN2211-X TRANSISTOR
Q803 UN2115-X D.TRANSISTOR
Q804 UN2111-X TRANSISTOR
Q900 UN2211-X TRANSISTOR
Q901 UN2211-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
Q903 UN2211-X TRANSISTOR
Q930 UN2211-X TRANSISTOR
D100 1SS133-T2 DIODE
D466 1SS133-T2 DIODE
D467 1SS133-T2 DIODE
D485 1SS133-T2 DIODE
D486 1SS133-T2 DIODE
D515 MTZJ3.9B-T2 Z DIODE
D516 MTZJ3.9B-T2 Z DIODE
D567 1SS133-T2 DIODE
D594 1SS133-T2 DIODE
D595 1SS133-T2 DIODE
D801 MTZJ5.1B-T2 Z DIODE
D803 1SS133-T2 DIODE
D804 1SS133-T2 DIODE
D805 1SS133-T2 DIODE
D806 1SS133-T2 DIODE
D807 1SS133-T2 DIODE
D808 1SS133-T2 DIODE
D809 MTZJ4.3B-T2 Z DIODE
D811 1SS133-T2 DIODE
D813 1SS133-T2 DIODE
D814 1SS133-T2 DIODE
D900 SLR-342VC-T LED
D901 SLR-342VC-T LED
D902 SLA-362LT-T LED
D903 SLA-362LT-T LED
D904 SLA-362LT-T LED
D905 SLA-362LT-T LED
D906 SLA-362LT-T LED
D907 SLA-362LT-T LED
D915 1SS133-T2 DIODE
D918 1SS133-T2 DIODE
D1003 MTZJ2.4B-T2 Z DIODE
C100 QEKC1HM-105Z E CAPACITOR 1uF 50V M
C101 NCB31HK-681X C CAPACITOR 680pF 50V K
C102 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C103 NCS31HJ-330X C CAPACITOR 33pF 50V J
C104 NCB31HK-182X C CAPACITOR 1800pF 50V K
C111 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C112 QETN1HM-106Z E CAPACITOR 10uF 50V M
C113 QETN1HM-106Z E CAPACITOR 10uF 50V M
C114 QETN1AM-227Z E CAPACITOR 220uF 10V M
C116 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C125 QETN1AM-477Z E CAPACITOR 470uF 10V M
C126 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C127 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C401 NCB31HK-471X C CAPACITOR 470pF 50V K
C402 QETN1EM-107Z E CAPACITOR 100uF 25V M
C403 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C404 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C405 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C406 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C407 NCB31HK-272X C CAPACITOR 2700pF 50V K
C408 NCB31HK-272X C CAPACITOR 2700pF 50V K
C409 QTE1H28-106Z E CAPACITOR 10uF 50V
C410 QTE1H28-106Z E CAPACITOR 10uF 50V
C411 QTE1H28-106Z E CAPACITOR 10uF 50V
C412 QTE1H28-106Z E CAPACITOR 10uF 50V
C413 QETN1HM-106Z E CAPACITOR 10uF 50V M
C414 QETN1HM-106Z E CAPACITOR 10uF 50V M
C415 QETN1HM-106Z E CAPACITOR 10uF 50V M
C416 QETN1HM-106Z E CAPACITOR 10uF 50V M
C417 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C418 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C419 QTE1H28-106Z E CAPACITOR 10uF 50V
C420 QTE1H28-106Z E CAPACITOR 10uF 50V
C421 NCB31HK-471X C CAPACITOR 470pF 50V K
C422 NCB31HK-471X C CAPACITOR 470pF 50V K
C423 QETN1EM-107Z E CAPACITOR 100uF 25V M
C425 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C432 NCS31HJ-101X C CAPACITOR 100pF 50V J
C433 NCS31HJ-101X C CAPACITOR 100pF 50V J
C446 QTE1H28-106Z E CAPACITOR 10uF 50V
C447 QTE1H28-106Z E CAPACITOR 10uF 50V
C450 QETN1EM-476Z E CAPACITOR 47uF 25V M
C451 QETN1HM-106Z E CAPACITOR 10uF 50V M
C452 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C453 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C454 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C455 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C456 QETN1HM-106Z E CAPACITOR 10uF 50V M
C457 QETN1HM-106Z E CAPACITOR 10uF 50V M
C458 QETN1HM-106Z E CAPACITOR 10uF 50V M
C459 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C460 QETN1HM-106Z E CAPACITOR 10uF 50V M
C461 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C462 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C463 QETN1EM-106Z E CAPACITOR 10uF 25V M
C464 QETN1HM-106Z E CAPACITOR 10uF 50V M
C466 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C467 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C468 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C469 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C470 NCB31HK-822X C CAPACITOR 8200pF 50V K
C471 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C472 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C473 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C474 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C475 NCB31HK-222X C CAPACITOR 2200pF 50V K
C476 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C477 QETN1CM-107Z E CAPACITOR 100uF 16V M
C485 NCB31CK-393X C CAPACITOR 0.039uF 16V K
C486 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C487 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C488 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C489 QETN1EM-476Z E CAPACITOR 47uF 25V M
C490 QETN1HM-105Z E CAPACITOR 1uF 50V M
C491 QETN1EM-476Z E CAPACITOR 47uF 25V M
C492 QETN1EM-476Z E CAPACITOR 47uF 25V M
 Symbol No. Part No. Part Name Description Local
