JVC HX-GX7

3-18
Loading switch board
Block No. [0][5][0][0]
Cassette switch board
Block No. [0][6][0][0]
Head amplifier board
Block No. [0][7][0][0]
R672 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R673 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R674 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R675 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R676 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R677 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R678 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R679 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R681 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R682 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R801 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R802 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R803 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R805 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R806 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R807 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R811 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R812 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R814 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R815 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R816 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R818 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
CN251 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN252 QGA2001F1-02 CONNECTOR W-B (1-2)
CN253 QGA2001F1-03 CONNECTOR W-B (1-3)
CN601 QGF1006F2-16W CONNECTOR FFC/FPC (1-16)
CN602 QGA2001F1-06 CONNECTOR W-B (1-6)
CN651 QGF1036F1-17 CONNECTOR FFC/FPC (1-17)
K654 NQR0007-002X FERRITE BEADS
X251 QAX0684-001Z C RESONATOR 8.38MHz
X651 NAX0476-001X CRYSTAL 33.8688MHz
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB1214J1-08S CONNECTOR B-B (1-8)
CN3 QGB1214K1-08S CONNECTOR B-B (1-8)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW7 QSW0886-002 DETECT SWITCH
SW8 QSW0886-002 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3-BB,C PHOTO SENSER
 Symbol No. Part No. Part Name Description Local
D1 1SR139-400-T2 SI DIODE
R371 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
VR37 QVP0077-103Z TRIM RESISTOR 10k Ω
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
P1 QNZ0104-001 POST PIN
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC32 HA12238F IC R/P Equalizer
IC33 CD4094BC IC
Serial to parallel
port extension
Q302 2SC2001/K/-T TRANSISTOR
Q305 2SC2001/K/-T TRANSISTOR
Q342 KRA111M-T DIGI TRANSISTOR
Q343 2SC3576-JVC-T TRANSISTOR
Q344 2SC3576-JVC-T TRANSISTOR
Q345 2SC3576-JVC-T TRANSISTOR
Q346 2SC3576-JVC-T TRANSISTOR
Q347 KRC107M-T DIGI TRANSISTOR
Q371 KTA1271/OY/-T TRANSISTOR
Q372 KRC107M-T DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 KTC3199/GL/-T TRANSISTOR
D340 MTZJ5.1B-T2 Z DIODE
D375 MTZJ5.1B-T2 Z DIODE
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C103 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C104 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C105 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C106 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C107 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C110 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C113 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C120 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C121 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C202 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C203 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C204 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C205 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C206 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C207 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C213 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C220 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C221 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C300 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C304 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C306 FQETJ1AM-227Z E CAPACITOR
C307 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
C310 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C316 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C319 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
 Symbol No. Part No. Part Name Description Local
