Specifications
Amplifier section—CA-HXD77
Output Power:
SUBWOOFERS: 180 W per channel, min. RMS,
driven into 3 Ω at 63 Hz with no
more than 10% total harmonic
distortion.
MAIN SPEAKERS: 90 W per channel, min. RMS,
driven into 6 Ω at 1 kHz with no
more than
10% total harmonic
distortion.
Audio input sensitivity/impedance
AUX: 400 mV/47 k Ω
USB: USB Version 1.1
Video input sensitivity/impedance
GAME/AUX(composite video): 1 V(p-p)/75 Ω
Digital output:
DIGITAL OUTPUT (OPTICAL):
–21 dBm to –15 dBm (660 nm ±30 nm)
VIDEO OUT:
Color system: NTSC or PAL
VIDEO (composite): 1 V(p-p)/75 Ω
S-VIDEO: Y (luminance) 1 V(p-p)/75 Ω
C (chrominance, burst)
NTSC 0.286 V(p-p)/75 Ω
PAL 0.3 V(p-p)/75 Ω
Speaker Terminals: 6 Ω – 16 Ω (main speakers)
3 Ω – 6 Ω (subwoofers)
Tuner section
FM tuning range: 87.5 MHz – 108.0 MHz
AM tuning range: 530 kHz – 1 710 kHz
Disc player section
Playable disc: DVD Video CD/VCD/SVCD
CD-R/CD-RW (recorded in Audio CD/
Video CD/Super Video CD/MP3/WMA/
JPEG format)
DVD-R/DVD-RW (recorded in DVD-Video
or DVD-VR format)
+R/+RW (recorded in DVD-Video or
DVD-VR format)
Dynamic range: 90 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
General
Power requirement: AC 120 V , 60 Hz
Power consumption: 90 W/ 150 VA (at operation)
8 W
(on standby; with power saving
off—Normal mode)
1 W (on standby; with power saving
on—Eco mode)
Dimensions (approx.): 175 mm x 373 mm x 411 mm
(6
15
/
16
in. x 14
11
/
16
in. x 16
3
/
16
in.)
(W/H/D)
Mass (approx.): 5.8 kg (12.8 lbs)
Supplied Accessories
See page 4.
Speaker section—SP-HXD77
Type: 4-Way Front Twin Woofer
(Magnetically Shielded Type)
Speakers:
Subwoofer: 16 cm (6
5
/
16
in.) cone x 1
Woofer: 16 cm (6
5
/
16
in.) cone x 1
Mid range: 7 cm (2
13
/
16
in.) cone x 1
Tweeter: 2 cm (
13
/
16
in.) piezo x 1
Power handling capacity:
Subwoofer: 180 W
Main speaker: 90 W
Impedance:
Subwoofer: 3 Ω
Main speaker: 6 Ω
Frequency range:
Subwoofer: 30 Hz – 1 000 Hz
Main speaker: 50 Hz – 20 000 Hz
Sound pressure level:
Subwoofer: 73 dB/W•m
Main speaker: 82 dB/W•m
Dimensions (approx.): 296 mm x 453 mm x 343 mm
(11
11
/
16
in. x 17
7
/
8
in. x 13
9
/
16
in.)
(W/H/D)
Mass (approx.): 7.5 kg (16.5 lbs) each
Design and specifications are subject to change without
notice.
