JVC HX-Z1R

To Next Page

To Previous Page

3-13

HX-Z1R

Item

Parts number Parts name Ar

Remarks

C 401 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 402 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 403 FQCF31HP-103Z C CAPACITOR

C 404 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 407 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 408 FQCF31HP-103Z C CAPACITOR

C 409 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 411 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 412 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 415 QDXB1CM-222Y C CAPACITOR

C 426 QDVB1EZ-223Y C CAPACITOR

C 427 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 435 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 436 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 437 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 438 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 442 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 444 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 445 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 446 QFLM1HJ-472Z M CAPACITOR 4700PF 5% 50V

C 447 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 448 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 449 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 450 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 451 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 452 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 453 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 454 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 455 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 456 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 457 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 458 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 459 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 460 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 461 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 462 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 463 QFG32AJ-222Z PP CAPACITOR 2200PF 5% 100V

C 464 QFG32AJ-222Z PP CAPACITOR 2200PF 5% 100V

C 465 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V

C 466 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V

C 467 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V

C 468 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V

C 469 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 470 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 471 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 472 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 473 QETN1EM-227Z E CAPACITOR 220MF 20% 25V

C 474 QFVJ1HJ-394Z MF CAPACITOR .39MF 5% 50V

C 475 QETN1AM-477Z E CAPACITOR 470MF 20% 10V

C 476 QTE1V06-106Z E CAPACITOR

C 477 QTE1V06-106Z E CAPACITOR

C 478 QTE1C06-476Z E CAPACITOR

C 479 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 480 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C 481 QTE1V06-106Z E CAPACITOR

C 482 QTE1V06-106Z E CAPACITOR

C 483 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 484 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 485 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 486 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 487 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 488 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 497 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 501 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 502 QFLM1HJ-153Z M CAPACITOR .015MF 5% 50V

C 503 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 504 QFLM1HJ-822Z M CAPACITOR 8200PF 5% 50V

C 505 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V

C 508 QFLM1HJ-273Z M CAPACITOR .027MF 5% 50V

C 509 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 510 QEKC1AM-107Z E CAPACITOR 100MF 20% 10V

C 514 QFLC1HJ-471Z M CAPACITOR 470PF 5% 50V

C 533 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 534 QFLM1HJ-153Z M CAPACITOR .015MF 5% 50V

C 536 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 537 QDGB1HK-681Y C CAPACITOR

C 538 QDXB1CM-182Y C CAPACITOR

C 539 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V

C 551 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 552 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 553 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 554 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 555 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 556 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 557 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 558 FQCF31HP-103Z C CAPACITOR

C 559 FQCF31HP-103Z C CAPACITOR

C 560 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 563 QDYB1CM-103Y C CAPACITOR

C 564 QDYB1CM-103Y C CAPACITOR

C 570 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 571 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 575 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 576 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 577 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 578 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 585 QETN1HM-476Z E CAPACITOR 47MF 20% 50V

C 587 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 588 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 590 QDGB1HK-102Y C CAPACITOR

C 591 QDGB1HK-102Y C CAPACITOR

C 595 QDYB1CM-103Y C CAPACITOR

CN 11 QGF1205F1-13 CONNECTOR

CN 44 QGF1201F3-10 CONNECTOR

CN217 QGB2510J1-07 CONNECTOR

CN311 QGB2510J1-11 CONNECTOR

CN661 QGF1036F1-19 FFC/FPC CONNE

CN870 QGF1205F1-23 CONNECTOR

D 409 DZ5.1BSB-T2 ZENER DIODE

D 411 1SS119-041-T2 SI DIODE

D 412 1SS119-041-T2 SI DIODE

D 426 DZ5.1BSB-T2 ZENER DIODE

D 448 1SS119-041-T2 SI DIODE

D 501 1SS119-041-T2 SI DIODE

D 502 1SS119-041-T2 SI DIODE

D 535 1SS119-041-T2 SI DIODE

D 545 1SS119-041-T2 SI DIODE

D 571 1SS119-041-T2 SI DIODE

D 572 1SS119-041-T2 SI DIODE

IC434 BH3874AKS2 IC

IC501 NJM4580D IC

IC502 NJM4580D IC

IC571 NJM4580D IC

J 411 QNN0420-001 PIN JACK

J 426 GP1FA550TZ OPT TRANSMITTER

L 533 QQR1277-001Z F.BEADS

Electrical parts list (Main board)
