HX-Z1R
3-14
Item
Parts number Parts name Ar
ea
Remarks
A
L 551 QQR1277-001Z F.BEADS
Q
401 2SC3576-JVC-T TRANSISTOR
Q
402 2SC3576-JVC-T TRANSISTOR
Q
493 2SC3576-JVC-T TRANSISTOR
Q
494 2SC3576-JVC-T TRANSISTOR
Q
495 2SC3576-JVC-T TRANSISTOR
Q
496 KRA102M-T D.TRANSISTOR
Q
533 2SC2785/FE/-T TRANSISTOR
Q
534 2SC2785/FE/-T TRANSISTOR
Q
545 KRA102M-T D.TRANSISTOR
Q
571 2SC2785/FE/-T TRANSISTOR
Q
572 2SC2785/FE/-T TRANSISTOR
Q
573 2SC2785/FE/-T TRANSISTOR
R 401 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 402 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 403 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 404 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 405 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 406 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 407 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 411 QRE141J-363Y C RESISTOR 36K 5% 1/4W
R 412 QRE141J-363Y C RESISTOR 36K 5% 1/4W
R 413 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 414 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 426 QRE141J-560Y C RESISTOR 56 5% 1/4W
R 435 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 440 QRE141J-912Y C RESISTOR 9.1K 5% 1/4W
R 442 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 443 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 444 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 445 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 446 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 447 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 450 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R 451 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 452 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 453 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 454 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 455 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 456 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 458 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 459 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 460 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 477 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 478 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 480 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 481 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 482 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 493 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 494 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 495 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 496 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 497 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 501 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 502 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 503 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 504 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 505 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 506 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 507 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 508 QRE141J-274Y C RESISTOR 270K 5% 1/4W
R 509 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 510 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 511 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 512 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 513 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 514 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 515 QRE141J-114Y C RESISTOR 110K 5% 1/4W
R 533 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R 534 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 535 QRE141J-225Y C RESISTOR 2.2M 5% 1/4W
R 536 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 537 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 538 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 545 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 546 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 551 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 552 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 553 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 554 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 570 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 571 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 572 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 573 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 575 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 576 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 577 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 579 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 580 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 581 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 582 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 583 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 585 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 587 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 588 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 589 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
SP434 GV40205-001A IC HOLDER
Electrical parts list (Main board)
Block No. 02
Item
Parts number Parts name Ar
ea
Remarks
A
