JVC HX-Z1R

3-15
HX-Z1R
Item
Parts number Parts name Ar
ea
Remarks
A
BZ801 QAN0045-001 BUZZER
C 201 QFKC2EK-104 METAL CAPACITOR .10MF 10% 250V
C 202 QFKC2EK-104 METAL CAPACITOR .10MF 10% 250V
C 203 QFKC2EK-104 METAL CAPACITOR .10MF 10% 250V
C 204 QEZ0581-478 E CAPACITOR 4700MF
C 205 QEZ0581-478 E CAPACITOR 4700MF
C 211 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C 212 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C 213 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C 214 QETM1VM-228 E CAPACITOR 2200MF 20% 35V
C 215 QETM1VM-228 E CAPACITOR 2200MF 20% 35V
C 217 QETN1JM-107Z E CAPACITOR 100MF 20% 63V
C 218 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C 219 QDYB1CM-103Y C CAPACITOR
C 220 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C 221 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 222 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 236 QETM1EM-338 E CAPACITOR 3300MF 20% 25V
C 240 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 260 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 601 FQCF31HZ-223Z D CAPACITOR
C 602 FQCF31HZ-223Z D CAPACITOR
C 603 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 604 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 605 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 606 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 607 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 608 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 609 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C 610 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C 611 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 612 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 613 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 614 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 615 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 616 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 618 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 621 QTE1V06-106Z E CAPACITOR
C 622 QTE1V06-106Z E CAPACITOR
C 623 QTE1V06-106Z E CAPACITOR
C 624 QTE1V06-106Z E CAPACITOR
C 639 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 651 QDYB1CM-103Y C CAPACITOR
C 652 QDYB1CM-103Y C CAPACITOR
C 653 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 654 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 732 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 733 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 734 QDYB1CM-103Y C CAPACITOR
C 735 QDYB1CM-103Y C CAPACITOR
C 736 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 737 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 801 FQCF31HP-103Z C CAPACITOR
C 803 QEKC0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 804 QEKC0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 805 QDGB1HK-102Y C CAPACITOR
C 806 QEKC0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 808 QCSB1HJ-270Y C CAPACITOR 27PF 5% 50V
C 809 QCSB1HJ-300Y C CAPACITOR 30PF 5% 50V
C 815 QEKC1HM-226Z E CAPACITOR 22MF 20% 50V
C 817 QEKC1HM-226Z E CAPACITOR 22MF 20% 50V
C 820 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 821 QDYB1CM-103Y C CAPACITOR
C 823 QFVJ1HJ-334Z MF CAPACITOR .33MF 5% 50V
C 825 QDGB1HK-102Y C CAPACITOR
C 831 QDYB1CM-103Y C CAPACITOR
C 832 QDYB1CM-103Y C CAPACITOR
C 835 QDGB1HK-102Y C CAPACITOR
C 836 QEKC1EM-106Z E CAPACITOR 10MF 20% 25V
C 837 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 838 QDGB1HK-102Y C CAPACITOR
C 840 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 889 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 901 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C 958 QDYB1CM-103Y C CAPACITOR
C 959 QDYB1CM-103Y C CAPACITOR
C 960 QDYB1CM-103Y C CAPACITOR
C 961 QDYB1CM-103Y C CAPACITOR
C 962 QDYB1CM-103Y C CAPACITOR
C 963 QDYB1CM-103Y C CAPACITOR
CN 43 QGF1210G1-09 CONNECTOR
CN205 QGB2510J1-15 CONNECTOR
CN206 QGA2501F1-02 CONNECTOR
CN207 QGB2510K2-07 CONNECTOR
CN701 QGD2503F1-04 SOCKET
CN860 QGF1210G1-23 CONNECTOR
CN880 QGF1210G1-13 CONNECTOR
CN890 QGF1205F1-13 CONNECTOR
CP 1 ICP-N15-T ICP
A
C1001 QDXB1CM-392Y C CAPACITOR
C1002 QDXB1CM-392Y C CAPACITOR
C1003 QDXB1CM-222Y C CAPACITOR
C1004 QDGB1HK-102Y C CAPACITOR
C1005 QDGB1HK-102Y C CAPACITOR
C1006 QDGB1HK-102Y C CAPACITOR
D 201 1N5402M-20 DIODE
A
D 202 1N5402M-20 DIODE
A
D 203 1N5402M-20 DIODE
A
D 204 1N5402M-20 DIODE
A
D 211 1N5402M-20 DIODE
A
D 212 1N5402M-20 DIODE
A
D 213 1N5402M-20 DIODE
A
D 214 1N5402M-20 DIODE
A
D 219 DZ33BSC-T2 ZENER DIODE
D 220 DZ9.1BSB-T2 ZENER DIODE
D 221 1SS119-041-T2 SI DIODE
D 240 DZ13BSB-T2 ZENER DIODE
D 260 1SS119-041-T2 SI DIODE
D 261 1SS119-041-T2 SI DIODE
D 262 1SS119-041-T2 SI DIODE
D 263 1SS119-041-T2 SI DIODE
D 264 DZ5.1BSB-T2 ZENER DIODE
D 619 1SS119-041-T2 SI DIODE
D 620 1SS119-041-T2 SI DIODE
D 622 DZ9.1BSB-T2 ZENER DIODE
D 650 1SS119-041-T2 SI DIODE
D 725 1SS119-041-T2 SI DIODE
D 801 1SS119-041-T2 SI DIODE
D 802 1SS119-041-T2 SI DIODE
D 803 11EQS03LN-T2 SB DIODE
D 804 1SS119-041-T2 SI DIODE
D 805 1SS119-041-T2 SI DIODE
D 806 1SS119-041-T2 SI DIODE
D 807 RB721Q-40-T2 SI DIODE
D 810 1SS119-041-T2 SI DIODE
D 815 DZ6.2BSC-T2 ZENER DIODE
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
ea
Remarks
A
