JVC HX-Z1R - Page 58

HX-Z1R
3-16
Item
Parts number Parts name Ar
ea
Remarks
A
D 816 DZ6.2BSC-T2 ZENER DIODE
D 831 DZ5.1BSB-T2 ZENER DIODE
D 832 DZ5.1BSB-T2 ZENER DIODE
D 833 DZ4.3BSB-T2 ZENER DIODE
D 901 L-192ZSRD-T LED
D 902 L-192ZSRD-T LED
D 903 L-192ZSRD-T LED
D 942 L-192ZSRD-T LED
D 943 L-192ZSRD-T LED
D 944 L-192ZSRD-T LED
D 945 L-192ZSRD-T LED
D 946 L-192ZSRD-T LED
D 947 L-192ZSRD-T LED
D 948 L-192ZSRD-T LED
D 950 L-192ZSRD-T LED
D 951 L-192ZSRD-T LED
D 962 L-192ZSRD-T LED
D 972 LC503MUR1-30Q LED
D 973 LC503MUR1-30Q LED
D1003 DZ2.4BSB-T2 ZENER DIODE
FL801 QLF0096-001 FL TUBE
FW202 QUM157-07DGZ4 FLAT WIRE
FW204 QJK015-050604 CONN.WIRE ASSY
FW221 QUM156-13DGZ4 FLAT WIRE
FW711 QUM154-33DGZ4 FLAT WIRE
FW800 QUM023-05Z4Z4 PARA RIBON WIRE
IC240 KIA7812API +12V REG.IC
A
IC602 STK402-030 IC
A
IC810 UPD784975AGF303 IC
IC811 BU2092 IC
IC951 GP1UM271XK IR DETECT UNIT
J 81 QNB0151-001 SPK TERMINAL
JS958 QSW0984-001 ROTARY ENCODER SEARCH
JS960 QSW0983-001 ROTARY ENCODER S/MODE VOL
JS962 QSW0862-001 ROTARY SWITCH MAIN VOL
J1001 QNS0204-001 3.5 JACK
L 601 QQLZ035-R39 INDUCTOR
L 602 QQLZ035-R39 INDUCTOR
L 801 QQL244K-100Z INDUCTOR
L 802 QQL231K-220Y INDUCTOR
L 803 QQL29BJ-100Z INDUCTOR
L 805 QQL244K-100Z INDUCTOR
L 806 QQL244K-100Z INDUCTOR
L 807 QQL231K-220Y INDUCTOR
L 815 QQR0621-001Z FERRITE BEADS
L 872 QQR0621-001Z FERRITE BEADS
L1001 QQL231K-470Y INDUCTOR
L1002 QQL231K-470Y INDUCTOR
L1003 QQR1277-001Z F.BEADS
Q
201 KTA1273/Y/-T TRANSISTOR
Q
260 KTC3203/OY/-T TRANSISTOR
Q
601 KTA1268/GL/-T TRANSISTOR
Q
602 KTA1268/GL/-T TRANSISTOR
Q
612 2SA1175/FE/-T TRANSISTOR
Q
613 KRC102M-T D.TRANSISTOR
Q
690 KTC3203/OY/-T TRANSISTOR
Q
733 2SC3576-JVC-T TRANSISTOR
Q
734 2SC3576-JVC-T TRANSISTOR
Q
735 2SC3576-JVC-T TRANSISTOR
Q
736 2SC3576-JVC-T TRANSISTOR
Q
737 KRA111M-T D.TRANSISTOR
Q
810 2SD1991A/RS/-T TRANSISTOR
Q
811 2SD1991A/RS/-T TRANSISTOR
Q
812 2SD1991A/RS/-T TRANSISTOR
Q
813 2SD1991A/RS/-T TRANSISTOR
Q
814 2SD1991A/RS/-T TRANSISTOR
Q
815 2SD1991A/RS/-T TRANSISTOR
Q
816 2SD1991A/RS/-T TRANSISTOR
Q
817 2SD1991A/RS/-T TRANSISTOR
Q
818 2SD1991A/RS/-T TRANSISTOR
Q
819 2SD1991A/RS/-T TRANSISTOR
Q
820 2SD1991A/RS/-T TRANSISTOR
Q
821 2SD1991A/RS/-T TRANSISTOR
Q
822 2SD1991A/RS/-T TRANSISTOR
Q
823 2SD1991A/RS/-T TRANSISTOR
Q
833 KRA111M-T D.TRANSISTOR
Q
858 2SD1991A/RS/-T TRANSISTOR
Q
875 KRC102M-T D.TRANSISTOR
Q
879 2SD1991A/RS/-T TRANSISTOR
Q
890 2SD1991A/RS/-T TRANSISTOR
Q
916 KTA1267/YG/-T TRANSISTOR
Q
917 KRC102M-T D.TRANSISTOR
Q
961 KTA1267/YG/-T TRANSISTOR
Q
962 KRC102M-T D.TRANSISTOR
R 202 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 203 QRE141J-752Y C RESISTOR 7.5K 5% 1/4W
R 204 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 205 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 215 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 216 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 217 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 218 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 240 QRZ9005-100X F RESISTOR
A
10 1/4W
R 260 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 261 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 262 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 263 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 601 QRJ146J-101X UNF C RESISTOR
A
100 5% 1/4W
R 602 QRJ146J-101X UNF C RESISTOR
A
100 5% 1/4W
R 603 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 604 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 605 FQRJ143J-122X UNF C RESISTOR
A
R 606 FQRJ143J-122X UNF C RESISTOR
A
R 607 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 608 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 613 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 614 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 615 FQRJ143J-100X UNF C RESISTOR
A
R 616 FQRJ143J-100X UNF C RESISTOR
A
R 617 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 618 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 619 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 620 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 621 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 623 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 637 QRJ146J-820X UNF C RESISTOR
A
82 5% 1/4W
R 639 QRL01DJ-821X OMF RESISTOR
A
820 5% 1W
R 640 QRL01DJ-821X OMF RESISTOR
A
820 5% 1W
R 650 FQRJ143J-4R7X UNF C RESISTOR
A
R 651 FQRJ143J-4R7X UNF C RESISTOR
A
R 653 QRT01DJ-R22X MF RESISTOR
A
5% 1W
R 655 QRT01DJ-R22X MF RESISTOR
A
5% 1W
R 666 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 667 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 668 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 674 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
ea
Remarks
A
