JVC HX-Z1R

3-17
HX-Z1R
Item
Parts number Parts name Ar
ea
Remarks
A
R 675 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 676 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 690 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 725 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 726 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 731 FQRJ143J-4R7X UNF C RESISTOR
A
R 732 FQRJ143J-4R7X UNF C RESISTOR
A
R 733 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 734 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 735 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 736 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 737 QRJ146J-820X UNF C RESISTOR
A
82 5% 1/4W
R 801 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 802 QRE141J-270Y C RESISTOR 27 5% 1/4W
R 805 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 806 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 807 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 808 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 810 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 811 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 812 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 813 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 814 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 815 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 816 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 817 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 818 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 819 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 820 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 821 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 822 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 823 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 824 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 825 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 826 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 827 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 828 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 829 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 830 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 831 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 832 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 833 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 834 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 835 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 836 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 837 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 838 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 839 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 840 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 841 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 842 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 843 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 844 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 845 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 846 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 847 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 848 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 849 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 850 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 851 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 852 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 853 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 854 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 855 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 856 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 857 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 858 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 859 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 860 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 861 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 862 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 863 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 865 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 866 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 867 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 868 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 869 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 870 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 871 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 872 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 873 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 876 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 877 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 878 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 879 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 880 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 881 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 882 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 883 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 884 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 885 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 886 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 887 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 888 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 889 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 890 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 891 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 892 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 893 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 894 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 895 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 896 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 897 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 899 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 900 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 901 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 902 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 903 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 904 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 905 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 906 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 907 QRE141J-163Y C RESISTOR 16K 5% 1/4W
R 908 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 909 QRE141J-334Y C RESISTOR 330K 5% 1/4W
R 911 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 912 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 913 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 916 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 917 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 918 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 919 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 920 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 921 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 922 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 923 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 924 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
ea
Remarks
A
