HX-Z1R
3-18
Item
Parts number Parts name Ar
ea
Remarks
A
R 925 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 926 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 927 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 928 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 929 QRE141J-753Y C RESISTOR 75K 5% 1/4W
R 930 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 931 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 932 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 933 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 934 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 935 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 936 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 937 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 938 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 939 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 940 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 941 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 942 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 943 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 944 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 945 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 946 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 947 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 948 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 949 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 950 QRE141J-334Y C RESISTOR 330K 5% 1/4W
R 952 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 953 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 954 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 955 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 956 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 957 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 958 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 959 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 960 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 961 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 962 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 963 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 969 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 970 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 971 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 972 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 973 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 975 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 976 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 978 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 980 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 981 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 982 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 983 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 984 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 985 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 986 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 987 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 988 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 989 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 990 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 991 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 992 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 993 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 994 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 995 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 996 QRE141J-104Y C RESISTOR 100K 5% 1/4W
RY 1 QSK0109-001 RELAY
RY 2 QSK0109-001 RELAY
S 900 QSW0674-001Z TACT SWITCH
S 901 QSW0674-001Z TACT SWITCH
S 902 QSW0674-001Z TACT SWITCH
S 903 QSW0674-001Z TACT SWITCH
S 904 QSW0674-001Z TACT SWITCH
S 905 QSW0674-001Z TACT SWITCH
S 906 QSW0674-001Z TACT SWITCH
S 920 QSW0674-001Z TACT SWITCH
S 921 QSW0674-001Z TACT SWITCH
S 922 QSW0674-001Z TACT SWITCH
S 923 QSW0674-001Z TACT SWITCH
S 924 QSW0674-001Z TACT SWITCH
S 925 QSW0674-001Z TACT SWITCH
S 926 QSW0674-001Z TACT SWITCH
S 927 QSW0674-001Z TACT SWITCH
S 928 QSW0674-001Z TACT SWITCH
S 940 QSW0674-001Z TACT SWITCH
S 941 QSW0674-001Z TACT SWITCH
S 942 QSW0674-001Z TACT SWITCH
S 943 QSW0674-001Z TACT SWITCH
S 944 QSW0674-001Z TACT SWITCH
S 945 QSW0674-001Z TACT SWITCH
S 946 QSW0674-001Z TACT SWITCH
S 947 QSW0674-001Z TACT SWITCH
S 948 QSW0674-001Z TACT SWITCH
S 949 QSW0674-001Z TACT SWITCH
SP801 VYH7653-001 IC HOLDER
X 801 QAX0724-001Z CRYSTAL
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
ea
Remarks
A
