JVC HX-Z1R

3-21
HX-Z1R
Item
Parts number Parts name Ar
ea
Remarks
A
R 641 NRSA63J-823X MG RESISTOR
R 642 NRSA63J-564X MG RESISTOR
R 651 NRSA63J-102X MG RESISTOR
R 652 NRSA63J-102X MG RESISTOR
R 653 NRSA63J-102X MG RESISTOR
R 654 NRSA63J-101X MG RESISTOR
R 655 NRSA63J-102X MG RESISTOR
R 656 NRSA63J-102X MG RESISTOR
R 657 NRSA63J-102X MG RESISTOR
R 658 NRSA63J-102X MG RESISTOR
R 659 NRSA63J-102X MG RESISTOR
R 662 NRSA63J-683X MG RESISTOR
R 663 NRSA63J-124X MG RESISTOR
R 664 NRSA63J-331X MG RESISTOR
R 665 NRSA63J-271X MG RESISTOR
R 666 NRSA63J-221X MG RESISTOR
R 667 NRSA63J-4R7X MG RESISTOR
R 668 NRSA63J-155X MG RESISTOR
R 670 NRSA63J-101X MG RESISTOR
R 672 NRSA63J-272X MG RESISTOR
R 682 NRSA63J-102X MG RESISTOR
R 691 NRSA63J-103X MG RESISTOR
R 692 NRSA63J-103X MG RESISTOR
R 695 NRSA63J-243X MG RESISTOR
R 696 NRSA63J-243X MG RESISTOR
R 701 NRSA63J-821X MG RESISTOR
R 702 NRSA63J-821X MG RESISTOR
R 703 NRSA63J-103X MG RESISTOR
R 704 NRSA63J-103X MG RESISTOR
R 705 NRSA63J-562X MG RESISTOR
R 706 NRSA63J-202X MG RESISTOR
R 707 NRSA63J-682X MG RESISTOR
R 708 NRSA63J-101X MG RESISTOR
R 709 NRSA63J-101X MG RESISTOR
R 710 NRSA63J-221X MG RESISTOR
R 801 NRSA63J-272X MG RESISTOR
R 802 NRSA63J-472X MG RESISTOR
R 803 NRSA63J-472X MG RESISTOR
R 804 NRSA63J-823X MG RESISTOR
R 805 NRSA63J-912X MG RESISTOR
R 806 NRSA63J-473X MG RESISTOR
R 807 NRSA63J-272X MG RESISTOR
R 808 NRSA63J-433X MG RESISTOR
R 809 NRSA63J-122X MG RESISTOR
R 811 NRSA63J-103X MG RESISTOR
R 831 NRSA63J-151X MG RESISTOR
R 832 NRSA63J-103X MG RESISTOR
R 842 NRSA63J-472X MG RESISTOR
R 851 NRSA63J-102X MG RESISTOR
R 852 NRSA63J-102X MG RESISTOR
R 853 NRSA63J-102X MG RESISTOR
R 854 NRSA63J-102X MG RESISTOR
R 861 NRSA63J-102X MG RESISTOR
R 862 NRSA63J-102X MG RESISTOR
R 863 NRSA63J-102X MG RESISTOR
R 864 NRSA63J-102X MG RESISTOR
R 865 NRSA63J-102X MG RESISTOR
R 866 NRSA63J-102X MG RESISTOR
R 880 NRSA63J-102X MG RESISTOR
R 881 NRSA63J-102X MG RESISTOR
R 882 NRSA63J-102X MG RESISTOR
R 883 NRSA63J-102X MG RESISTOR
R 884 NRSA63J-102X MG RESISTOR
R 885 NRSA63J-102X MG RESISTOR
R 886 NRSA63J-102X MG RESISTOR
R 887 NRSA63J-102X MG RESISTOR
W 601 QUB220-07HPDT SIN TWIST WIRE
X 251 QAX0720-001Z C RESONATOR
X 651 QAX0413-001Z CRYSTAL
Item
Parts number Parts name Ar
ea
Electrical parts list (CD switch board )
Remarks
Block No. 06
A
CN804 QGB2016J1-07 CONNECTOR
CN805 QGB2012J1-10 CONNECTOR
SW 1 QSW0859-001 LEVER SWITCH
SW 2 QSW0859-001 LEVER SWITCH
SW 3 QSW0859-001 LEVER SWITCH
SW 4 QSW0859-001 LEVER SWITCH
SW 5 QSW0859-001 LEVER SWITCH
SW 6 QSW0859-001 LEVER SWITCH
Electrical parts list (CD servo board)
Block No. 05
Item
Parts number Parts name Ar
ea
Remarks
A
